Upgrade Your CNC Machining with the MWLNL2525M06 External Tool Holder
-
Overview
Introducing the MWLNL2525M06 External Tool Holder, engineered for precision and reliability in high-performance CNC machining applications. With a unique 95° cutting edge angle and a robust multi-lock system, this tool holder ensures maximum stability and accuracy during machining. Designed for compatibility with various WNMG blades, the MWLNL2525M06 is the perfect solution for CNC lathes and machining centers, enhancing your productivity and machining quality. Whether you're in a professional shop or a manufacturing setting, this tool holder is a valuable addition to your toolkit.
-
Features and Specifications
- Model:MWLNL2525M06
- Package Includes: MWLNL2525M06 Tool Holder and compatible Shim,Pin,Clamp, Screws, and Wrenches
- 95° cutting edge angle and 0° relief angle.
- Type: M-Type (Multi-Lock system)
- Shank width: 25mm
- Shank length: 25mm
- Total Length: 150mm
- Shim: MW0604
- Pin: CTM513
- Clamp: HL1813
- Screw: ML0625
- Wrench:L2.0 L3.0
- Compatible Blades: WNMG060404 WNMG060408 WNMG060412 WNMG331 WNMG332 WNMG333
-
Key Features of the MWLNL2525M06 Tool Holder
-
5-Point Description
-
-
High Precision Cutting Edge Angle: The MWLNL2525M06 features an impressive 95° cutting edge angle, allowing for superior accuracy and clean cuts, perfect for intricate machining tasks.
-
Robust Multi-Lock System: This external cylindrical tool holder employs a multi-lock system that ensures a secure grip on the cutting tool, reducing tool movement and enhancing stability during operation.
-
Versatile Blade Compatibility: Designed to work seamlessly with multiple WNMG blades, including WNMG060404, WNMG060408, and WNMG332, the MWLNL2525M06 offers flexibility for various machining applications.
-
Compact and Durable Construction: With a shank width and length of 25mm and a total length of 150mm, this tool holder is built for durability and performance, making it suitable for both tight and expansive machining environments.
-
Complete Accessory Package: Each MWLNL2525M06 includes essential accessories such as shim (MW0603), pin (CTM513), clamp (HL1813), screw (ML0625), and wrenches (L2.0 & L3.0), ensuring easy installation and adjustments.
-
Technical FAQ & Buying Guide
Absolutely. Our CNC carbide inserts (including CNMG, WNMG, DNMG, and APMT series) are manufactured strictly adhering to international ISO/ANSI specifications. A CNMG 120408 from OYYU BEYOND will flawlessly fit any standard turning tool holder or indexable tool from major global brands like Sandvik Coromant, Kennametal, Iscar, Walter, or SECO, providing a highly cost-effective premium alternative without sacrificing tolerance or tool life.
We offer optimized CVD and PVD multi-layer coatings for different ISO material groups:
- For Carbon/Alloy Steel (ISO P): Choose our thick multi-layer CVD coated grades (e.g., Al2O3 + TiN). They provide exceptional crater wear resistance and thermal barriers during high-speed dry or wet roughing.
- For Stainless Steel (ISO M): Choose our nano-structured PVD coated grades with sharp, positive chipbreakers (like -TM or -MA). This combination prevents work hardening and effectively controls sticky chips.
The optimal cutting parameters vary depending on the workpiece hardness and operation type:
- For General Steel Turnings: Recommended cutting speed ($V_c$) ranges from 150 to 280 m/min, with a feed rate ($f$) of 0.15 to 0.45 mm/rev.
- For Stainless Steel Finishing: Recommended cutting speed ($V_c$) is 120 to 200 m/min, with a feed rate ($f$) of 0.10 to 0.25 mm/rev.Always adjust parameters based on early wear patterns: increase $V_c$ if built-up edge occurs, or reduce $V_c$ if severe flank wear is observed.
Yes, we support machine shops, distributors, and global buyers with tiered wholesale pricing and competitive volume discounts. We also provide OEM custom manufacturing solutions for tool holders and carbide inserts based on your technical drawings. Contact our team to request a quick B2B quotation.
We provide secure worldwide express shipping (via DHL, FedEx, and UPS) with specialized, vibration-proof industrial packaging to ensure tools arrive in perfect condition. In-stock items are dispatched within 24-48 hours, while custom or bulk orders typically have a stable lead time of 15-25 days.
All our cutting tools and tool holders are manufactured strictly in accordance with ISO 9001 and international industrial standards. Every batch undergoes 100% rigorous quality control testing using high-precision optical measuring equipment to ensure reliable tool life and stable performance in continuous mass production.
