MGEHR1010-2 MGEHR 1010-2 External Grooving Turning Tool for High Precision CNC Machining
Price shown is a starting point. Contact us for a precise quote based on your requirements.
Description:
The MGEHR1010-2 External Grooving Turning Tool, an essential component for precision machining.
With a compact lathe size of 10x10x100mm and a cutting width of 2mm, compatible with MGMN200-M inserts
Product parameters:
-
Tool Holder Model: MGEHR1010-2
-
Tool Holder Material : Carbide Steel, Carbon Steel
-
Tool Holder Size : About 10 * 10 * 100 mm
-
Cutting Width : About 2 mm
-
Applicable blade : MGMN200-M
-
Screw : M4*16
- Wrench : L3
- Detailed Dimensions of the tool holder :as pictured
Package Contents:
1 * MGEHR1010-2 holder
1 * "L" Type wrench
1 * M4*16 Type Screw
Features:
1.High-Quality Construction,ensures longevity and reliability
2.Unparalleled performance and tight tolerances
3.High grip, strong impact resistance, obvious speed advantage
4.Designed for precise grooving, ideal for complex machining tasks
5.The user can easily clamp and replace the blade and gasket with just a wrench
BEYOND MGEHR1010-2 External Grooving Turning Tools MGEHR1010-2 MGEHR 1010 MGEHR1010 2 CNC Lathe Cutter Holder Machine Metal Tool
-
Unlock Precision with the MGEHR1010-2 Tool Holder
-
Key Features of the MGEHR1010-2 External Grooving Tool
-
The Essential Tool for Efficient Machining
-
Compact and Durable Design
-
Exceptional Performance with Tight Tolerances
-
User-Friendly for Quick Blade Changes
5-Point Description
- Robust Construction: The MGEHR1010-2 is built with high-quality materials that ensure durability and longevity, making it a reliable choice for all your machining projects.
- Precision Grooving Capabilities: Designed for a cutting width of 2mm, this tool holder provides precise and clean cuts, making it perfect for intricate machining tasks.
- Versatile Compatibility: This tool is compatible with MGMN200-M inserts, allowing for a wide range of applications, from basic to complex machining needs.
- Easy Installation: The package includes M4*16 screws and a convenient L3 wrench, enabling quick and hassle-free blade and gasket replacements to minimize downtime.
- Compact Size: Measuring 10x10x100mm, this external grooving tool fits seamlessly into your existing CNC setup, making it an ideal addition to your toolkit.
Technical FAQ & Buying Guide
Absolutely. Our CNC carbide inserts (including CNMG, WNMG, DNMG, and APMT series) are manufactured strictly adhering to international ISO/ANSI specifications. A CNMG 120408 from OYYU BEYOND will flawlessly fit any standard turning tool holder or indexable tool from major global brands like Sandvik Coromant, Kennametal, Iscar, Walter, or SECO, providing a highly cost-effective premium alternative without sacrificing tolerance or tool life.
We offer optimized CVD and PVD multi-layer coatings for different ISO material groups:
- For Carbon/Alloy Steel (ISO P): Choose our thick multi-layer CVD coated grades (e.g., Al2O3 + TiN). They provide exceptional crater wear resistance and thermal barriers during high-speed dry or wet roughing.
- For Stainless Steel (ISO M): Choose our nano-structured PVD coated grades with sharp, positive chipbreakers (like -TM or -MA). This combination prevents work hardening and effectively controls sticky chips.
The optimal cutting parameters vary depending on the workpiece hardness and operation type:
- For General Steel Turnings: Recommended cutting speed ($V_c$) ranges from 150 to 280 m/min, with a feed rate ($f$) of 0.15 to 0.45 mm/rev.
- For Stainless Steel Finishing: Recommended cutting speed ($V_c$) is 120 to 200 m/min, with a feed rate ($f$) of 0.10 to 0.25 mm/rev.Always adjust parameters based on early wear patterns: increase $V_c$ if built-up edge occurs, or reduce $V_c$ if severe flank wear is observed.
Yes, we support machine shops, distributors, and global buyers with tiered wholesale pricing and competitive volume discounts. We also provide OEM custom manufacturing solutions for tool holders and carbide inserts based on your technical drawings. Contact our team to request a quick B2B quotation.
We provide secure worldwide express shipping (via DHL, FedEx, and UPS) with specialized, vibration-proof industrial packaging to ensure tools arrive in perfect condition. In-stock items are dispatched within 24-48 hours, while custom or bulk orders typically have a stable lead time of 15-25 days.
All our cutting tools and tool holders are manufactured strictly in accordance with ISO 9001 and international industrial standards. Every batch undergoes 100% rigorous quality control testing using high-precision optical measuring equipment to ensure reliable tool life and stable performance in continuous mass production.
