Negative Turning Insert Sumitomo

Coated Carbide: AC820P,Designation:CNMG120408N-UP AC820P CNMG432EUP:AC820P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC830P,Designation:CNMG120408N-SU AC830P CNMG432ESU:AC830P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts.With Hole...

Coated Carbide: AC820P,Designation:CNMG120408N-SU AC820P CNMG432ESU:AC820P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Cermet:AC700G ,Designation:CNMG120408N-SU AC700G  CNMG432ESU:AC700G .Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide: AC630M,Designation:CNMG120408N-SU AC630M CNMG432ESU:AC630M.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:Continuous Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC510U,Designation:CNMG120408N-SU AC510U CNMG432ESU:AC510U.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:Continuous Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole Application...

Coated Carbide:AC830P,Designation:CNMG120408N-MX AC830P CNMG432EMX:AC830P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range...

Coated Carbide:AC830P,Designation:CNMG120408N-MU AC830P CNMG432EMU:AC830P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range...

Coated Carbide:AC630M,Designation:CNMG120404N-GU AC630M CNMG431EGU:AC630M.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:Continuous Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts With Hole Application Range

Coated Carbide:AC6030M,Designation:CNMG120404N-GU AC6030M CNMG431EGU:AC6030M.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:Continuous Cutting 1st Recommended Turning 80˚ Diamond Negative Inserts .With Hole Application Range

Coated Carbide: AC830P,Designation:CNMM190616N-HG AC830P  CNMG644EHG:AC830P .Nose Radius RE:.0625. Dimension (inch):Cutting Edge Length L:7598,Thickness S:.2500.Inscribed Circle IC:.7500,Hole Dia.D1:.3126 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole...

Coated Carbide: AC830P,Designation:CNMM190612N-HG AC830P  CNMG643EHG:AC830P .Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:7598,Thickness S:.2500.Inscribed Circle IC:.7500,Hole Dia.D1:.3126 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole...

Coated Carbide: AC830P,Designation:CNMM160616N-HG AC830P CNMG544EHG:AC830P.Nose Radius RE:.0625. Dimension (inch):Cutting Edge Length L:6339,Thickness S:.2500.Inscribed Circle IC:.6250,Hole Dia.D1:.2500 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole...

Coated Carbide: AC830P,Designation:CNMM160612N-HG AC830P CNMG543EHG:AC830P .Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:6339,Thickness S:.2500.Inscribed Circle IC:.6250,Hole Dia.D1:.2500 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole...

Coated Carbide:AC830P ,Designation:CNMG190616N-MU AC830P  CNMG644EMU:AC830P .Nose Radius RE:.0625. Dimension (inch):Cutting Edge Length L:7598,Thickness S:.2500.Inscribed Circle IC:.7500,Hole Dia.D1:.3126 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts Application Range...

Coated Carbide:AC8025P,Designation:CNMG190616N-MU AC8025P CNMG644EMU:AC8025P.Nose Radius RE:.0625. Dimension (inch):Cutting Edge Length L:7598,Thickness S:.2500.Inscribed Circle IC:.7500,Hole Dia.D1:.3126 Recommended Application: Steel: General Cutting 1st Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide: AC830P,Designation:CNMG190608N-UX AC830P CNMG642EUX:AC830P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:7598,Thickness S:.2500.Inscribed Circle IC:.7500,Hole Dia.D1:.3126 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole...

Coated Carbide:AC630M,Designation:CNMG160612N-MU AC630M CNMG543EMU:AC630M.Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:6339,Thickness S:.2500.Inscribed Circle IC:.6250,Hole Dia.D1:.2500 Recommended Application:Stainless Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC520U,Designation:CNMG160612N-MU AC520U  CNMG543EMU:AC520U.Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:6339,Thickness S:.2500.Inscribed Circle IC:.6250,Hole Dia.D1:.2500 Recommended Application: Steel:General Cutting 1st Recommended,Stainless Steel:General Cutting 1st Recommended,Cast Iron:General Cutting 1st Recommended Turning 80˚ Diamond...

Coated Carbide:AC820P,Designation:CNMG160608N-GU AC820P CNMG542EGU:AC820P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6339,Thickness S:.2500.Inscribed Circle IC:.6250,Hole Dia.D1:.2500 Recommended Application: Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide: AC830P,Designation:CNMG120412N-UX AC830P CNMG433EUX:AC830P.Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole...

Coated Carbide:AC830P,Designation:CNMG120412N-MU AC830P  CNMG433EGU:AC830P.Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts Application Range...

Coated Carbide:AC820P,Designation:CNMG120412N-MU AC820P CNMG433EGU:AC820P.Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC630M,Designation:CNMG120412N-MU AC630M CNMG433EGU:AC630M.Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:Continuous Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC530U,Designation:CNMG120412N-MU AC530U  CNMG433EGU:AC530U.Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 1st Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC520U,Designation:CNMG120412N-MU AC520U  CNMG433EMU:AC520U.Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 1st Recommended,Stainless Steel:General Cutting 1st Recommended,Cast Iron:General Cutting 1st Recommended Turning 80˚ Diamond...

Coated Carbide:AC630M,Designation:CNMG120412N-GU AC630M CNMG433EGU:AC630M.Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC530U,Designation:CNMG120412N-GU AC530U CNMG433EGU:AC530U.Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 1st Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC830P ,Designation:DNMG150404N-GU AC830P  Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:nterrupted Cutting 2nd Recommended Turning 55˚ Diamond Positive Inserts.With Hole Application Range

Coated Carbide:AC820P ,Designation:DNMG150404N-GU AC820P  Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:General Cutting 2nd Recommended,Cast Iron:nterrupted Cutting 2nd Recommended Turning 55˚ Diamond Positive Inserts.With Hole Application Range...

Coated Carbide:AC630M ,Designation:DNMG150404N-EX AC630M  Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:nterrupted Cutting 2nd Recommended Turning 55˚ Diamond Positive Inserts.With Hole Application Range

Coated Carbide:AC520U,Designation:DNMG150404N-EX AC520U Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Exotic Alloy:General Cutting 2nd Recommended Turning 55˚ Diamond Positive Inserts.With Hole Application Range

Coated Carbide:AC820P,Designation:DNMG150608N-GU AC820P Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.2500.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:General Cutting 2nd Recommended,Cast Iron:nterrupted Cutting 2nd Recommended Application Range

Coated Carbide:AC810P,Designation:DNMG150608N-GU AC810P Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.2500.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:Continuous Cutting 2nd Recommended Turning 55˚ Diamond Positive Inserts.With Hole Application Range

Coated Carbide:AC630M ,Designation:DNMG150608N-GU AC630M Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.2500.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:nterrupted Cutting 2nd Recommended Turning 55˚ Diamond Positive Inserts.With Hole Application Range

Coated Carbide:AC820P ,Designation:DNMG150604N-SU AC820P Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.2500.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:General Cutting 2nd Recommended,Cast Iron:nterrupted Cutting 2nd Recommended Application Range

Coated Carbide:AC630M ,Designation:DNMG150604N-EX AC630M Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.2500.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:nterrupted Cutting 2nd Recommended Turning 55˚ Diamond Positive Inserts.With Hole Application Range

Coated Carbide:AC830P,Designation:DNMG150408N-UX AC830P Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:Interrupted Cutting 2nd Recommended Application Range

Coated Carbide:AC810P,Designation:DNMG150408N-UX AC810P Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:Continuous Cutting 2nd Recommended Application Range

Coated Carbide:AC820P ,Designation:DNMG150408N-SU AC820P Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:General Cutting 2nd Recommended,Cast Iron:nterrupted Cutting 2nd Recommended Application Range

Coated Carbide:AC520U,Designation:DNMG150408N-MU AC520U Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Exotic Alloy:General Cutting 2nd Recommended Application Range

Coated Carbide:AC510U ,Designation:DNMG150408N-MU AC510U  Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Exotic Alloy:Continuous Cutting 2nd Recommended Application Range

Coated Carbide:AC820P ,Designation:DNMG150408N-GU AC820P  Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:General Cutting 2nd Recommended,Cast Iron:nterrupted Cutting 2nd Recommended Turning 55˚ Diamond Positive Inserts.With Hole Application Range...

Coated Carbide:AC700G,Designation:DNMG150408N-GU AC700G Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:Continuous Cutting 2nd Recommended,Cast Iron:nterrupted Cutting 2nd Recommended Turning 55˚ Diamond Positive Inserts.With Hole Application Range...

Coated Carbide:AC520U,Designation:DNMG150408N-GU AC520U Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Exotic Alloy:General Cutting 2nd Recommended Turning 55˚ Diamond Positive Inserts.With Hole Application Range

Coated Carbide:AC530U,Designation:DNMG150404N-SU AC530U Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6102,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Exotic Alloy:Interrupted Cutting 2nd Recommended Turning 55˚ Diamond Positive Inserts.With Hole Application Range

Coated Carbide:AC630M,Designation:SNMG190616N-MU AC630M Nose Radius RE:.0625. Dimension (inch):Cutting Edge Length L:7500,Thickness S:.2500.Inscribed Circle IC:.7500,Hole Dia.D1:.3126 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning Square Negative Inserts  Application Range

Coated Carbide:AC630M,Designation:SNMG190612N-MU AC630M Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:7500,Thickness S:.2500.Inscribed Circle IC:.7500,Hole Dia.D1:.3126 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning Square Negative Inserts  Application Range
