Sumitomo

Coated Carbide:AC830P,Designation:CNMG120404N-GU AC830P CNMG431EGU:AC830P.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts .With Hole...

Coated Carbide: AC520U,Designation:CNMG120404N-SU AC520U CNMG431ESU:AC520U.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 1st Recommended,Stainless Steel:General Cutting 1st Recommended,Cast Iron:General Cutting 1st Recommended Turning 80˚...

Coated Carbide: AC530U,Designation:CNMG120404N-SU AC530U CNMG431ESU:AC530U.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 1st Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC630M,Designation:CNMG120404N-SU AC630M CNMG431ESU:AC630M.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:Continuous Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC700G ,Designation:CNMG120404N-SU AC700G  CNMG431ESU:AC700G .Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC810P,Designation:CNMG120404N-SU AC810P CNMG431ESU:AC810P.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC820P,Designation:CNMG120404N-SU AC820P CNMG431ESU:AC820P.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC830P,Designation:CNMG120404N-SU AC830P CNMG431ESU:AC830P.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole...

Cermet: T1500A,Designation:CNMG120404N-SU T1500A CNMG431ESU:T1500A.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC520U,Designation:CNMG120404N-SU AC520U CNMG431EUP:AC520U.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC830P,Designation:CNMG120404N-UP AC830P CNMG431EUP:AC830P.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole...

Coated Carbide: AC830P,Designation:CNMG120404N-UX AC830P Nose Radius RE:.0156. Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC830P,Designation:CNMG120404N-UG AC830P CNMG431ENG:AC830P.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended  Turning 80˚ Diamond Negative Inserts.With Hole...

Coated Carbide: AC820P,Designation:CNMG120404N-UX AC820P CNMG431EUX:AC820P.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC510U,Designation:CNMG120408N-EG AC510U CNMG432EEG:AC510U.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:Continuous Cutting 2nd Recommended,,Cast Iron:Interrupted Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts.With Hole...

Coated Carbide: AC520U,Designation:CNMG120408N-EG AC520U CNMG432EEG:AC520U.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 1st Recommended,Stainless Steel:General Cutting 1st Recommended,Cast Iron:General Cutting 1st Recommended Turning 80˚...

Coated Carbide: AC6040M,Designation:CNMG120408N-EG AC6040M CNMG432EEG:AC6040M.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:General Cutting 1st Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC520U,Designation:CNMG120408N-EX AC520U CNMG432EEX:AC520U.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 1st Recommended,Stainless Steel:General Cutting 1st Recommended,Cast Iron:General Cutting 1st Recommended Turning 80˚...

Coated Carbide:AC6040M,Designation:CNMG120404N-GU AC6040M  CNMG431EGU:AC6040M.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:General Cutting 1st Recommended Turning 80˚ Diamond Negative Inserts With Hole Application Range

Coated Carbide: AC530U,Designation:CNMG120408N-EX AC530U CNMG432EEX:AC530U .Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 1st Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide: AC630M,Designation:CNMG120408N-EX AC630M CNMG432EEX:AC630M.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts.With Hole Application Range

Coated Carbide:AC810P,Designation:CNMG120408N-GU AC810P CNMG432EGU:AC810P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC520U,Designation:CNMG120408N-GU AC520U CNMG432EGU:AC520U.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 1st Recommended,Stainless Steel:General Cutting 1st Recommended,Cast Iron:General Cutting 1st Recommended Turning 80˚ Diamond...

Coated Carbide:AC820P,Designation:CNMG120408N-MU AC820P CNMG432EMU:AC820P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC630M,Designation:CNMG120408N-MU AC630M CNMG432EMU:AC630M.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Stainless Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range

Cermet:AC700G ,Designation:CNMG120408N-GU AC700G  CNMG432EGU:AC700G.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC8025P,Designation:CNMG120408N-GU AC8025P CNMG432EGU:AC8025P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 1st Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC830P ,Designation:CNMG120408N-GU AC830P  CNMG432EGU:AC830P .Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 2nd Recommended,Cast Iron:Interrupted Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range...

Coated Carbide:AC820P,Designation:CNMG120408N-GU AC820P CNMG432EGU:AC820P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:Continuous Cutting 2nd Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC520U,Designation:CNMG120408N-GU AC520U CNMG432EGZ:AC520U.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application:Cast Iron:General Cutting 1st Recommended Turning 80˚ Diamond Negative Inserts Application Range

Coated Carbide:AC520U,Designation:CNMG120408N-MU  AC520U CNMG432EMU:AC520U.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2031 Recommended Application: Steel:General Cutting 1st Recommended,Stainless Steel:General Cutting 1st Recommended,Cast Iron:General Cutting 1st Recommended Turning 80˚ Diamond...

Coated Carbide: AC630M ,Designation:CCMT09T308N-MU AC630M CCMT32.52EMU:AC630M .Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:3819,Thickness S:.1563.Inscribed Circle IC:.3750,Hole Dia.D1:.1732 Recommended Application:Stainless Steel:General Cutting 1st Recommended Turning 80˚ Diamond Positive Inserts.7° Pos.With Hole...

Coated Carbide: AC823P,Designation:CCMT120404N-SU AC830P CCMT431ESU:AC823P.Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2165 Recommended Application: Steel:Interrupted Cutting 2nd Recommended. Turning 80˚ Diamond Positive Inserts.7° Pos.With Hole Application Range...

Coated Carbide: AC820P,Designation:CCMT120408N-SU AC820P CCMT432EFM:AC820P.Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:5079,Thickness S:.1875.Inscribed Circle IC:.5000,Hole Dia.D1:.2165 Recommended Application: Steel:Interrupted Cutting 2nd Recommended Cast Iron:Interrupted Cutting 2nd Recommended. Turning 80˚ Diamond Positive...

Coated Carbide:H1 Designation:APET160508PDFR-S H1 S: For Aluminum Alloy.Nose Radius RE:0.031 / 0.8.   marked inserts require modification of the cutter body. Correct the tool diameter by +0.5mm before use. High-speed...

Coated Carbide:H1 Designation:APET103504PDFR-S H1 S: For Aluminum Alloy.Nose Radius RE:0.016 / 0.4. High-speed / Light:Work Material:Cast Iron,Aluminu Alloy.Hardness:250HB. Cutting Speed vc (m/min) Min. - Optimum - Max.:70-150-180,200-300-500. Feed Rate fz...

Coated Carbide:ACZ330 Designation:APMT103504PDER-H ACZ330 Nose Radius RE:0.016 / 0.4.-H: Strong Edge Type. General-purpose:P:Work Material:Carbon Steel.Hardness:180 to 280 HB Cutting Speed vc (m/min) Min. - Optimum - Max.:80- 120 -160. Feed...

Coated Carbide:ACZ330 Designation:APMT103508PDER-H ACZ330 Nose Radius RE:0.032 / 0.8.-H: Strong Edge Type. General-purpose: P:Work Material:Carbon Steel.Hardness:180 to 280 HB Cutting Speed vc (m/min) Min. - Optimum - Max.:80- 120 -160....

Coated Carbide:ACZ310 Designation:APMT160508PDER-H ACZ310 S: For Aluminum Alloy.Nose Radius RE:0.031 / 0.8.   marked inserts require modification of the cutter body. Correct the tool diameter by +0.5mm before use.  ...

Coated Carbide:ACZ330 Designation:APMT160508PDER-H ACZ330 H:Strong Edge Type..Nose Radius RE:0.031 / 0.8.   marked inserts require modification of the cutter body. Correct the tool diameter by +0.5mm before use. General-purpose:P:Work Material:Carbon...

Coated Carbide:ACZ330 Designation:APMT160520PDER-H ACZ330 H:Strong Edge Type..Nose Radius RE:0.079 / 2.0.   marked inserts require modification of the cutter body. Correct the tool diameter by +0.5mm before use. General-purpose:P:Work Material:Carbon...

Carbide:H1,Designation:AXET123504PEFR-S H1 Nose Radius RE:016" / 0.4,S:For Aluminum Alloy. High-speed / Light:K,N

Carbide:H1,Designation:AXET123504PEFR-S H1 Nose Radius RE:032" / 0.8,S:For Aluminum Alloy. High-speed / Light:K,N

DLC:DL1000 ,Designation:AXET170504PEFR-S DL1000 Nose Radius RE:.0.16, High-speed / Light:N General-purpose:N

Carbide:H1,Designation:AXET170504PEFR-S H1  Nose Radius RE:.0.16, High-speed / Light:K,N

Carbide:H1,Designation:AXET170508PEFR-S H1 Nose Radius RE:.0.31, High-speed / Light:N General-purpose:N

Coated Carbide:ACP200 ,Designation:AXMT123504PEER-G ACP200 Nose Radius RE:.016" / 0.4,Wiper Facet Length wpr:.047" / 1.2 G:General-purpose, General-purpose:P,M Roughing:P,M

Coated Carbide:ACP200 ,Designation:AXMT123504PEER-H ACP200  Nose Radius RE:.016" / 0.4,Wiper Facet Length wpr:.047" / 1.2 -H: Strong Edge General-purpose:P,M Roughing:P,M
