Sumitomo

Cermet:T1500A ,Designation:TPMT090204N-LU T1500A TPMT1.81.51ELU T1500A Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:3780,Thickness S:.0937.Inscribed Circle IC:.2189,Hole Dia.D1:.1102 Recommended Application:Steel:General Cutting 1st Recommended Turning Triangular Positive Inserts Application Range

Coated Carbide:AC630M,Designation:TPMT110304N-MU AC630M TPMT221EMU AC630M Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:4331,Thickness S:.1250.Inscribed Circle IC:.2500,Hole Dia.D1:.1339 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning Triangular Positive Inserts Application Range

Coated Carbide:AC530U,Designation:TPMT110304N-SU AC530U TPMT221ESU AC530U Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:4331,Thickness S:.1250.Inscribed Circle IC:.2500,Hole Dia.D1:.1339 Recommended Application:Exotic Alloy:Interrupted Cutting 2nd Recommended Turning Triangular Positive Inserts Application Range

Coated Carbide:AC6030M,Designation:TPMT110304N-SU AC6030M TPMT221ESU AC6030M Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:4331,Thickness S:.1250.Inscribed Circle IC:.2500,Hole Dia.D1:.1339 Recommended Application:Stainless Steel:General Cutting 1st Recommended Turning Triangular Positive Inserts Application Range

Coated Carbide:AC530U,Designation:TPMT110308N-SU AC530U TPMT222ESU AC530U Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:4331,Thickness S:.1250.Inscribed Circle IC:.2500,Hole Dia.D1:.1339 Recommended Application:Exotic Alloy:Interrupted Cutting 2nd Recommended Turning Triangular Positive Inserts Application Range

Coated Carbide:AC630M,Designation:TPMT160404N-SU AC630M TPMT331ESU AC630M Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6496,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1732 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning Triangular Positive Inserts Application Range

Coated Carbide:AC820P,Designation:TPMT160404N-SU AC820P TPMT331ESU AC820P Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6496,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1732 Recommended Application:Steel:General Cutting 2nd Recommended,Cast Iron:nterrupted Cutting 2nd Recommended Turning Triangular Positive Inserts Application Range...

Coated Carbide:AC820P,Designation:TPMT160408N-SU AC820P TPMT332ESU AC820P Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6496,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1732 Recommended Application:Steel:General Cutting 2nd Recommended,Cast Iron:nterrupted Cutting 2nd Recommended Turning Triangular Positive Inserts Application Range...

Coated Carbide:AC820P,Designation:VBMT160404N-SU AC820P VBMT331ESU AC820P Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1732 Recommended Application:Steel:General Cutting 2nd Recommended,Cast Iron:nterrupted Cutting 2nd Recommended Turning 35˚ Diamond Positive Inserts Application...

Coated Carbide:AC520U,Designation:VCGT110302R-FY AC520U VCGT220.5RFY AC520U Nose Radius RE:.0078. Dimension (inch):Cutting Edge Length L:4370,Thickness S:.1250.Inscribed Circle IC:.2500,Hole Dia.D1:.1102 Recommended Application:Exotic Alloy:General Cutting 2nd Recommended Turning 35˚ Diamond Positive Inserts Application Range

Coated Carbide:AC630M,Designation:VCMT110302N-SU AC630M VCMT220.5ESU AC630M Nose Radius RE:.0078. Dimension (inch):Cutting Edge Length L:4370,Thickness S:.1250.Inscribed Circle IC:.2500,Hole Dia.D1:.1102 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Positive Inserts Application Range

Coated Carbide:AC630M,Designation:VCMT110304N-SU AC630M VCMT221ESU AC630M Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:4370,Thickness S:.1250.Inscribed Circle IC:.2500,Hole Dia.D1:.1102 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Positive Inserts Application Range

Coated Carbide:AC520U,Designation:VNMG160402N-SU AC520U VNMG330.5ESU AC520U Nose Radius RE:.0078. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Exotic Alloy:General Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC530U ,Designation:VNMG160402N-SU AC530U  VNMG330.5ESU AC530U Nose Radius RE:.0078. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Exotic Alloy:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC630M,Designation:VNMG160402N-SU AC630M VNMG330.5ESU AC630M Nose Radius RE:.0078. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC630M,Designation:VNMG160404N-EX AC630M VNMG331EEX AC630M Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC520U ,Designation:VNMG160404N-GU AC520U  VNMG331EGU AC520U Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Exotic Alloy:General Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC530U,Designation:VNMG160404N-GU AC530U VNMG331EGU AC530U Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Exotic Alloy:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC6030M,Designation:VNMG160404N-GU AC6030M VNMG331EGU AC6030M Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Stainless Steel:General Cutting 1st Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC820P ,Designation:VNMG160404N-GU AC820P VNMG331EGU AC820P Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Exotic Alloy:General Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC830P,Designation:VNMG160404N-GU AC830P VNMG331EGU AC830P Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC510U,Designation:VNMG160404N-SU AC510U VNMG331ESU AC510U Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Exotic Alloy:Continuous Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC520U,Designation:VNMG160404N-SU AC520U VNMG331ESU AC520U Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Exotic Alloy:General Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC530U,Designation:VNMG160404N-SU AC530U  VNMG331ESU AC530U Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Exotic Alloy:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC630M,Designation:VNMG160404N-SU AC630M VNMG331ESU AC630M Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC810P,Designation:VNMG160404N-SU AC810P VNMG331ESU AC810P Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Steel:Continuous Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC820P,Designation:VNMG160404N-SU AC820P VNMG331ESU AC820P Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Exotic Alloy:Continuous Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC830P ,Designation:VNMG160404N-SU AC830P  VNMG331ESU AC830P  Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Cermet:T1500A,Designation:VNMG160404N-SU T1500A VNMG331ESU T1500A Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Steel:General Cutting 1st Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC830P,Designation:VNMG160404N-UP AC830P VNMG331EUP AC830P Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC630M ,Designation:TPMT110304N-SU AC630M  TPMT221ESU AC630M Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:4331,Thickness S:.1250.Inscribed Circle IC:.2500,Hole Dia.D1:.1339 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning Triangular Positive Inserts Application Range

Coated Carbide:AC630M,Designation:VNMG160404N-GU AC630M VNMG331EGU AC630M Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC630M,Designation:VNMG160408N-EX AC630M VNMG331=2EEX AC630M Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC6030M,Designation:VNMG160408N-GU AC6030M VNMG332EGU AC6030M Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Stainless Steel:General Cutting 1st Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC630M ,Designation:VNMG160408N-GU AC630M VNMG332EGU AC630MNose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC700G,Designation:VNMG160408N-GU AC700G VNMG332EGU AC700G Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Steel:Continuous Cutting 2nd Recommended.Cast Iron:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application...

Coated Carbide:AC820P ,Designation:VNMG160408N-GU AC820P  VNMG332EGU AC820P  Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Steel:General Cutting 2nd Recommended,Cast Iron:nterrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application...

Coated Carbide:AC630M,Designation:VNMG160408N-SU AC630M VNMG332ESU AC630M Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC830P,Designation:VNMG160404N-SU AC830P VNMG331ESU AC830P Nose Radius RE:.0156. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Stainless Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC830P,Designation:VNMG160408N-UP AC830P VNMG332EUP AC830P Nose Radius RE:.0313. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Steel:Interrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application Range

Coated Carbide:AC830P,Designation:VNMG160404N-UP AC830P VNMG333EUP AC830P Nose Radius RE:.0469. Dimension (inch):Cutting Edge Length L:6535,Thickness S:.1875.Inscribed Circle IC:.3750,Hole Dia.D1:.1500 Recommended Application:Steel:General Cutting 2nd Recommended,Cast Iron:nterrupted Cutting 2nd Recommended Turning 35˚ Diamond Negative Inserts Application...

Coated Carbide:ACP300,Designation:WDXT042004-G ACP300.Width W1:0.1969 (5.0),Thickness S:0.0984 (2.5),Nose Radius RE:0.0157 (0.4) G Type: General-purpose Applicable Holder (Inch / Metric):WDX0625D2S100 to WDX0687D2S100 WDX155D2S20 to WDX180D2S25 General-purpose:P,M.Roughing:P,M Indexable Insert Drills WDX Type Inserts 2D...

Coated Carbide:ACP300,Designation:WDXT063006-G ACP300.Width W1:0.2362 (6.0),Thickness S:0.1181 (3.0),Nose Radius RE:0.0236 (0.6) G Type: General-purpose Applicable Holder (Inch / Metric):WDX0750D2S100 to  WDX0875D2S100 WDX185D2S25 to WDX225D2S25 General-purpose:P,M.Roughing:P,M Indexable Insert Drills WDX Type Inserts 2D...

Coated Carbide:ACP300,Designation:WDXT073506-G ACP300.Width W1:0.2953 (7.5),Thickness S:0.1378 (3.5),Nose Radius RE:0.0236 (0.6) G Type: General-purpose Applicable Holder (Inch / Metric):WDX0937D2S125 to WDX1125D2S125 WDX230D2S25 to WDX285D2S32 General-purpose:P,M.Roughing:P,M Indexable Insert Drills WDX Type Inserts 2D...

Coated Carbide:ACP300,Designation:WDXT073506-L ACP300.Width W1:0.2953 (7.5),Thickness S:0.1378 (3.5),Nose Radius RE:0.0236 (0.6) Applicable Holder (Inch / Metric):WDX0937D2S125 to WDX1125D2S125 WDX230D2S25 to WDX285D2S32 General-purpose:P,M.Roughing:P,M Indexable Insert Drills WDX Type Inserts 2D (Internal Coolant Supply)...

Coated Carbide:ACP300,Designation:WDXT094008-G ACK300.Width W1:0.3780 (9.6),Thickness S:0.1575 (4.0),Nose Radius RE:0.0315 (0.8) Applicable Holder (Inch / Metric):WDX1187D2S125 to WDX1437D2S150 WDX290D2S32 to WDX360D2S40 Roughing:K Indexable Insert Drills WDX Type Inserts 2D (Internal Coolant Supply)...

Coated Carbide:ACP300,Designation:WDXT094008-G ACP300.Width W1:0.3780 (9.6),Thickness S:0.1575 (4.0),Nose Radius RE:0.0315 (0.8) Applicable Holder (Inch / Metric):WDX1187D2S125 to WDX1437D2S150 WDX290D2S32 to WDX360D2S40 General-Purpose:P,M.RoughingP,M Indexable Insert Drills WDX Type Inserts 2D (Internal Coolant...

Coated Carbide:ACP300,Designation:WDXT125012-G ACP300.Width W1:0.4882 (12.4),Thickness S:0.1969 (5.0),Nose Radius RE:0.0472 (1.2) Applicable Holder (Inch / Metric):WDX1500D2S150 to WDX1750D2S150 WDX370D2S40 to WDX450D2S40 General-Purpose:P,M.RoughingP,M Indexable Insert Drills WDX Type Inserts 2D (Internal Coolant Supply)...
