Kyocera

CVD Coated Carbide:CA6525,Designation:WNMG080404MS CA6525 ANSI:WNMG431MS CA6525 Corner Radius(in) RE:1/64,Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Specialized carbide substrate for machining stainless steel with excellent notching resistance and toughness Application: First choice...

PVD Coated Carbide:PR1125,Designation:WNMG080404MS PR1125 ANSI:WNMG431MS PR1125 Stainless Steel:Light Interruption / 2nd Choice HRSA:Light Interruption / 2nd Choice Corner Radius(in) RE:1/64,Color: Purple Red Coating / Main Component: TiAlN Advantages:Hard TiAlN base PVD...

MEGACOAT / MEGACOAT NANO PVD Coated Carbide:PR1535,Designation:WNMG080404MS PR1535 ANSI:WNMG431MS PR1535 Stainless Steel:Light Interruption / 1st Choice HRSA:Light Interruption / 1st Choice. Titanium Alloy:Light Interruption / 1st Choice Corner Radius(in) RE:1/64,Color:...

MEGA COAT Cermet:PV720,Designation:WNMG080404PP PV720 ANSI:WNMG331PP PV720 Carbon/Alloy Steel:Light Interruption / 1st Choice Corner Radius(in) RE:1/64,Color: Gold Coating / Main Component: TiCN (MEGACOAT NANO) Advantages:Superior wear and adhesion resistant MEGACOAT NANO on wear resistant,...

MEGA COAT Cermet:PV720,Designation:WNMG080404PQ PV720 ANSI:WNMG331PQ PV720 Carbon/Alloy Steel:Light Interruption / 1st Choice Corner Radius(in) RE:1/64,Color: Gold Coating / Main Component: TiCN (MEGACOAT NANO) Advantages:Superior wear and adhesion resistant MEGACOAT NANO on...

CVD Coated Carbide:CA5525,Designation:WNMG080404PS CA5525 ANSI:WNMG331PS CA5525 Carbon/Alloy Steel:Light Interruption / 2st Choice Corner Radius(in) RE:1/64,Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application: For general machining of steel, roughing to interruption PP:...

CVD Coated Carbide:CA6525,Designation:WNMG080404PS CA6525 ANSI:WNMG431PS CA6525 Corner Radius(in) RE:1/64,Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Specialized carbide substrate for machining stainless steel with excellent notching resistance and toughness Application: First choice for...

CVD Coated Carbide:CA6525,Designation:WNMG080404TK CA6525 ANSI:WNMG431TK CA6525 Corner Radius(in) RE:1/64,Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Specialized carbide substrate for machining stainless steel with excellent notching resistance and toughness Application: First choice...

PVD Coated Carbide:PR1115,Designation:WNMG080404TK PR1125 ANSL:WNMG431TK PR1125 ,Stainless Steel:Light Interruption / 2nd Choice,HRSA:Light Interruption / 2nd Choice Corner Radius(in) RE:1/64,Color:Purple Red Coating / Main Component:TiAlN, Advantages:Hard TiAlN base PVD coated super micro-grain carbide,...

CVD Coated Carbide:CA4505,Designation:WNMG080408 CA4505 ANSI:WNMG432 CA4505   Corner Radius(in) RE:1/32,Color:Blackish Gray Coating / Main Component: TiCN+Al2O3 Advantages:Stable, longer tool life due to improved bonding strength of coating layers and special...

CVD Coated Carbide:CA4515,Designation:WNMG080408 CA4515 ANSI:WNMG432 CA4515   Corner Radius(in) RE:1/32 Color:Blackish Gray, Coating / Main;Component:TiCN+Al2O3, Advantages:Stable, longer tool life due to improved bonding strength of coating layers and special treatment...

CVD Coated Carbide:PR1125,Designation:WNMG080408 PR1125 ANSI:WNMG432 PR1125 Stainless Steel:Light Interruption / 2nd Choice,HRSA:Light Interruption / 2nd Choice Corner Radius(in) RE:1/32,,Color:Purple Red Coating / Main Component:TiAlN, Advantages:Hard TiAlN base PVD coated super micro-grain...

Cermet:TN60,Designation:WNMG080408 TN60 ANSI:WNMG432 TN60 Corner Radius(in) RE:1/32,Color: Gray, Coating / Main Component: TiCN+NbC Advantages:Application: Machining of steel, continuous to interruption TURNING INSERTS (NEGATIVE)

CVD Coated Carbide:CA4515,Designation:WNMG080408C CA4515 ANSI:WNMG432C CA4515   Corner Radius(in) RE:1/32 Color:Blackish Gray, Coating / Main;Component:TiCN+Al2O3, Advantages:Stable, longer tool life due to improved bonding strength of coating layers and special treatment...

CVD Coated Carbide:CA510,Designation:WNMG080408CQ CA510 ANSI:WNMG432CQ CA510 Carbon/Alloy Steel:Continuous / 2nd Choice Corner Radius(in) RE:1/32 Color:Gold Coating / Main;Component:TiCN+Al2O3+TiN Advantages:Special substrate with thermal deformation resistance along with a thick and tough coating...

CVD Coated Carbide:CA515,Designation:WNMG080408CQ CA515 ANSI:WNMG432CQ CA515Carbon/Alloy Steel:Continuous / 1nd Choice Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Improved wear resistance and stability due to special substrate with heat...

CVD Coated Carbide:CA525,Designation:WNMG080408CQ CA525 ANSI:WNMG432CQ CA525 Carbon/Alloy Steel:Light Interruption / 2nd Choice Corner Radius(in) RE:1/32 Color:Gold Coating / Main;Component:TiCN+Al2O3+TiN Advantages:Stable and long tool life machining due to special substrate with...

CVD Coated Carbide:CA5515,Designation:WNMG080408CQ CA5515 ANSI:WNMG432CQ CA5515 Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application: Machining of steel, continuous to light interruption CQ:Good chip control at various D.O.C. such...

CVD Coated Carbide:CA5525,Designation:WNMG080408CQ CA5525 ANSI:WNMG432CQ CA5525 Carbon/Alloy Steel:Light Interruption / 2nd Choice Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application: For general machining of steel, roughing to interruption...

CVD Coated Carbide:CA5525,Designation:WNMG080408GS CA5525 ANSI:WNMG432GS CA5525 Carbon/Alloy Steel:Light Interruption / 2nd Choice Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application: For general machining of steel, roughing to interruption...

CVD Coated Carbide:CA5525,Designation:WNMG080408GT CA5525 ANSI:WNMG432GT CA5525 Carbon/Alloy Steel:Light Interruption / 2nd Choice Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application: For general machining of steel, roughing to interruption...

CVD Coated Carbide:CA5515,Designation:WNMG080408HQ CA5515 ANSI:WNMG432HQ CA5515  Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application: Machining of steel, continuous to light interruption HQ: Sharp cutting performance with 3-D rake...

CVD Coated Carbide:CA6525,Designation:WNMG080408HQ CA6525 ANSI:WNMG432HQ CA6525 Corner Radius(in) RE:1/32,Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Specialized carbide substrate for machining stainless steel with excellent notching resistance and toughness Application: First choice...

CVD Coated Carbide:PR1125,Designation:WNMG080408HQ PR1125 ANSI:WNMG432HQ PR1125 Stainless Steel:Light Interruption / 2nd Choice,HRSA:Light Interruption / 2nd Choice Corner Radius(in) RE:1/32,,Color:Purple Red Coating / Main Component:TiAlN, Advantages:Hard TiAlN base PVD coated super micro-grain...

Cermet:TN60,Designation:WNMG080408HQ TN60 ANSI:WNMG432HQ TN60 Corner Radius(in) RE:1/32,Color: Gray, Coating / Main Component: TiCN+NbC Advantages:Application: Machining of steel, continuous to interruption HQ: Sharp cutting performance with 3-D rake angle and double projection design....

Cermet:TN6020,Designation:WNMG080408HQ TN6020 ANSI:WNMG432 TN6020 Corner Radius(in) RE:1/32,Color: Gray, Coating / Main Component: TiCN Advantages:Application: Uncoated cermet for steel HQ: Sharp cutting performance with 3-D rake angle and double projection design. TURNING INSERTS...

Cermet:TN620,Designation:WNMG080408HQ TN620 ANSI:WNMG432HQ TN620 Carbon/Alloy Steel:Light Interruption / 1st Choice Corner Radius(in) RE:1/32,Color: Gray Coating / Main Component: TiCN Advantages:High wear resistance and chipping resistance cermet due to three hybrid technology attributes ...

Cermet:TN60,Designation:WNMG080408HS TN60 ANSI:WNMG432HS TN60 Corner Radius(in) RE:1/32,Color: Gray, Coating / Main Component: TiCN+NbC Advantages:Application: Machining of steel, continuous to interruption HS:General purpose chipbreaker.Applicable for copying. TURNING INSERTS (NEGATIVE)

CVD Coated Carbide:CA6515,Designation:WNMG080408MQ CA6515 ANSI:WNMG432MQ CA6515 Stainless Steel:Continuous / 1st Choice HRSA:Continuous / 2st Choice Corner Radius(in) RE:1/32,Color:Gold Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application:Specialized carbide substrate for machining stainless steel,...

CVD Coated Carbide:CA6525,Designation:WNMG080408MQ CA6525 ANSI:WNMG432MQ CA6525 Stainless Steel:Light Interruption / 1st Choice HRSA:Light Interruption / 2st Choice Corner Radius(in) RE:1/32,Color:Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Specialized carbide substrate for machining...

CVD Coated Carbide:CA6525,Designation:WNMG080408MS CA6525 ANSI:WNMG432MS CA6525 Stainless Steel:Light Interruption / 1st Choice HRSA:Light Interruption / 2st Choice Corner Radius(in) RE:1/32,Color:Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Specialized carbide substrate for machining stainless...

CVD Coated Carbide:PR1125,Designation:WNMG080408MS PR1125 ANSI:WNMG432MS PR1125 Stainless Steel:Light Interruption / 2nd Choice,HRSA:Light Interruption / 2nd Choice Corner Radius(in) RE:1/32,,Color:Purple Red Coating / Main Component:TiAlN, Advantages:Hard TiAlN base PVD coated super micro-grain...

MEGACOAT / MEGACOAT NANO PVD Coated Carbide:PR1310,Designation:WNMG080408MS PR1310 ANSI:WNMG432MS PR1310  Corner Radius(in) RE:1/32,Color:Blackish Red Coating / Main Component: MEGACOAT Advantages:MEGACOAT on hard and superior heat-resistant carbide, superior wear and oxidation resistance...

MEGACOAT / MEGACOAT NANO PVD Coated Carbide:PR1535,Designation:WNMG080408MS PR1535 ANSI:WNMG432MS PR1535 Stainless Steel:Light Interruption / 1st Choice HRSA:Light Interruption / 1st Choice,Titanium Alloy:Light Interruption / 1st Choice Corner Radius(in) RE:1/32,Color:Blackish Red Coating /...

CVD Coated Carbide:PR1125,Designation:WNMG080408MU PR1125  ANSI:WNMG432MU PR1125 Stainless Steel:Light Interruption / 2nd Choice,HRSA:Light Interruption / 2nd Choice Corner Radius(in) RE:1/32,,Color:Purple Red Coating / Main Component:TiAlN, Advantages:Hard TiAlN base PVD coated super micro-grain...

MEGACOAT / MEGACOAT NANO PVD Coated Carbide:PR1310,Designation:WNMG080408MU PR1310  ANSI:WNMG432MU PR1310  Corner Radius(in) RE:1/32,Color:Blackish Red Coating / Main Component: MEGACOAT Advantages:MEGACOAT on hard and superior heat-resistant carbide, superior wear and oxidation resistance...

MEGACOAT / MEGACOAT NANO PVD Coated Carbide:PR1535,Designation:WNMG080408MU PR1535 ANSI:WNMG432MU PR1535 Stainless Steel:Light Interruption / 1st Choice HRSA:Light Interruption / 1st Choice,Titanium Alloy:Light Interruption / 1st Choice Corner Radius(in) RE:1/32,Color:Blackish Red Coating / Main...

CVD Coated Carbide:CA515,Designation:WNMG080408PG CA515 ANSI:WNMG432PG CA515 Carbon/Alloy Steel:Continuous / 1nd Choice Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Improved wear resistance and stability due to special substrate with...

CVD Coated Carbide:CA515,Designation:WNMG080408PQ CA515 ANSI:WNMG432PQ CA515 Carbon/Alloy Steel:Continuous / 1nd Choice Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Improved wear resistance and stability due to special substrate with heat...

CVD Coated Carbide:CA5515,Designation:WNMG080408PS CA5515 ANSI:WNMG432PS CA5515  Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application: Machining of steel, continuous to light interruption PS:General purpose chipbreaker.More stable due to large...

CVD Coated Carbide:CA5525,Designation:WNMG080408PS CA5525 ANSI:WNMG432PS CA5525 Carbon/Alloy Steel:Light Interruption / 2nd Choice Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application: For general machining of steel, roughing to interruption...

CVD Coated Carbide:CA6515,Designation:WNMG080408PS CA6515 ANSI:WNMG432MQ CA6515 Stainless Steel:Continuous / 1st Choice HRSA:Continuous / 2st Choice Corner Radius(in) RE:1/32,Color:Gold Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application:Specialized carbide substrate for machining stainless steel,...

CVD Coated Carbide:CA6525,Designation:WNMG080408PS CA6525 ANSI:WNMG432PS CA6525 Stainless Steel:Light Interruption / 1st Choice HRSA:Light Interruption / 2st Choice Corner Radius(in) RE:1/32,Color:Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Specialized carbide substrate for machining...

PVD Coated Carbide:PR1125,Designation:WNMG080408PS PR1125 ANSI:WNMG432PS PR1125 Stainless Steel:Light Interruption / 2nd Choice,HRSA:Light Interruption / 2nd Choice Corner Radius(in) RE:1/32,,Color:Purple Red Coating / Main Component:TiAlN, Advantages:Hard TiAlN base PVD coated super micro-grain carbide,...

CVD Coated Carbide:CA5525,Designation:WNMG080408PT CA5525 ANSI:WNMG432PT CA5525 Carbon/Alloy Steel:Light Interruption / 2nd Choice Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application: For general machining of steel, roughing to interruption...

CVD Coated Carbide:CA5535,Designation:WNMG080408PT CA5535 ANSI:WNMG432PT CA5535 Carbon/Alloy Steel:Interruption / 2nd Choice Corner Radius(in) RE:1/32 Color: Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Application: Roughing to heavily interrupted machining of steel PS:General purpose...

CVD Coated Carbide:CA6525,Designation:WNMG080408TK CA6525 ANSI:WNMG432TK CA6525 Stainless Steel:Light Interruption / 1st Choice HRSA:Light Interruption / 2st Choice Corner Radius(in) RE:1/32,Color:Gold, Coating / Main Component: TiCN+Al2O3+TiN Advantages:Specialized carbide substrate for machining stainless...

CVD Coated Carbide:CA525,Designation:WNMG080412CQ CA525 ANSI:WNMG433CQ CA525 Carbon/Alloy Steel:Light Interruption / 2nd Choice Corner Radius(in) RE:3/64 Color:Gold Coating / Main;Component:TiCN+Al2O3+TiN Advantages:Stable and long tool life machining due to special substrate with...
