14mm T-Slot Milling Cutter carbide end milll
Price shown is a starting point. Contact us for a precise quote based on your requirements.
14mm T-Slot Milling Cutter
The 14mm T-Slot Milling Cutter is a high-performance solid carbide cutter designed for precision CNC machining of T-slots, keyseats, and undercuts. Manufactured from ultra-fine grain carbide with TiAlN coating, it ensures durability, excellent surface finish, and long-lasting performance in high-speed operations.
Product Features
- Cutting Diameter (D1): 14mm
- Material: Solid carbide with TiAlN coating
- Tool Type: T-Slot Milling Cutter / Keyseat Cutter
- Cutting Direction: Right-hand cutting
- Shank Type: Cylindrical shank for universal CNC use
- Applications: T-slot, keyseat, and undercut machining
Technical Specifications
| Parameter | Value |
|---|---|
| Tool Type | T-Slot Milling Cutter |
| D1 (Cutting Diameter) | 14mm |
| Shank Diameter (d) | 12mm |
| Cutting Length (l1) | 9mm |
| Total Length (L) | 70mm |
| Number of Teeth (z) | 6 |
Recommended Cutting Parameters
| Work Material | Spindle Speed (RPM) | Feed Rate (mm/min) | Depth of Cut (mm) |
|---|---|---|---|
| Carbon Steel | 4800–7200 | 350–650 | 0.3–0.6 |
| Stainless Steel | 3600–6000 | 300–500 | 0.2–0.5 |
| Aluminum & Copper | 9000–12000 | 800–1200 | 0.5–1.0 |
Applications
- Machining precision T-slots in machine tables and fixtures
- Keyseat and undercut cutting on shafts and components
- Profile slotting in dies, molds, and jigs
- General high-speed CNC machining and mold making
Advantages
- Ultra-hard carbide substrate ensures superior tool life
- Precision-ground cutting edges minimize vibration and chatter
- Optimized geometry for smooth chip evacuation
- Coating enhances oxidation and heat resistance
Product Dimensions
| Model | d1 (Cutting Diameter) | d (Shank Diameter) | l1 (Cutting Length) | L (Total Length) | z (Teeth) |
|---|---|---|---|---|---|
| TSC-14 | 14mm | 12mm | 9mm | 70mm | 6 |
Why Choose Our 14mm Carbide T-Slot Milling Cutter?
Our 14mm T-Slot Milling Cutters deliver precision, durability, and performance for professional CNC machinists. Built with advanced carbide materials and strict quality standards, these tools ensure high accuracy and smooth cutting for demanding manufacturing applications.
SEO Keywords & Long-tail Keywords
14mm T-slot milling cutter, carbide keyseat cutter, CNC slotting tool, 14mm keyway cutter, solid carbide T-slot cutter, T-slot end mill 14mm, CNC keyseat milling tool, carbide slot milling cutter
Technical FAQ & Buying Guide
Absolutely. Our CNC carbide inserts (including CNMG, WNMG, DNMG, and APMT series) are manufactured strictly adhering to international ISO/ANSI specifications. A CNMG 120408 from OYYU BEYOND will flawlessly fit any standard turning tool holder or indexable tool from major global brands like Sandvik Coromant, Kennametal, Iscar, Walter, or SECO, providing a highly cost-effective premium alternative without sacrificing tolerance or tool life.
We offer optimized CVD and PVD multi-layer coatings for different ISO material groups:
- For Carbon/Alloy Steel (ISO P): Choose our thick multi-layer CVD coated grades (e.g., Al2O3 + TiN). They provide exceptional crater wear resistance and thermal barriers during high-speed dry or wet roughing.
- For Stainless Steel (ISO M): Choose our nano-structured PVD coated grades with sharp, positive chipbreakers (like -TM or -MA). This combination prevents work hardening and effectively controls sticky chips.
The optimal cutting parameters vary depending on the workpiece hardness and operation type:
- For General Steel Turnings: Recommended cutting speed ($V_c$) ranges from 150 to 280 m/min, with a feed rate ($f$) of 0.15 to 0.45 mm/rev.
- For Stainless Steel Finishing: Recommended cutting speed ($V_c$) is 120 to 200 m/min, with a feed rate ($f$) of 0.10 to 0.25 mm/rev.Always adjust parameters based on early wear patterns: increase $V_c$ if built-up edge occurs, or reduce $V_c$ if severe flank wear is observed.
Yes, we support machine shops, distributors, and global buyers with tiered wholesale pricing and competitive volume discounts. We also provide OEM custom manufacturing solutions for tool holders and carbide inserts based on your technical drawings. Contact our team to request a quick B2B quotation.
We provide secure worldwide express shipping (via DHL, FedEx, and UPS) with specialized, vibration-proof industrial packaging to ensure tools arrive in perfect condition. In-stock items are dispatched within 24-48 hours, while custom or bulk orders typically have a stable lead time of 15-25 days.
All our cutting tools and tool holders are manufactured strictly in accordance with ISO 9001 and international industrial standards. Every batch undergoes 100% rigorous quality control testing using high-precision optical measuring equipment to ensure reliable tool life and stable performance in continuous mass production.
