16mm T-Slot Milling Cutter
The 16mm T-Slot Milling Cutter is designed for precision machining of T-shaped slots and keyways in various materials such as alloy steel, cast iron, and stainless steel. Made from high-quality tungsten carbide, this cutter ensures high wear resistance, excellent rigidity, and long tool life under high-speed CNC milling conditions.
Features
- Made of ultra-fine grain carbide for superior durability.
- Optimized cutting edge for smooth slotting and reduced vibration.
- Ideal for T-slot and keyway machining on CNC milling centers.
- Available with TiAlN or AlTiN coating for enhanced performance.
- Precision-ground shank for stable tool clamping and accuracy.
Specifications
| Model | T-Slot Milling Cutter |
|---|---|
| Cutting Diameter (d1) | 16 mm |
| Shank Diameter (d2) | 16 mm |
| Cutting Width (b) | 6 mm |
| Neck Diameter (d3) | 10 mm |
| Overall Length (L) | 80 mm |
| Material | Solid Carbide |
| Coating | TiAlN / AlTiN / Uncoated |
| Application | Steel, Stainless Steel, Cast Iron, Alloy |
Applications
This cutter is widely used in the manufacturing of molds, fixtures, and machine components requiring precise T-shaped or keyway slots. It provides reliable performance in both dry and wet cutting conditions.
Recommended for CNC Machines
- Vertical CNC Milling Machines
- Machining Centers
- High-speed Milling Equipment
Why Choose Our T-Slot Milling Cutter?
Our carbide 16mm T-Slot Milling Cutter is engineered to provide outstanding performance, excellent surface finish, and reduced tool wear. It’s a perfect solution for manufacturers seeking precision and efficiency in slot milling operations.
Related Keywords
T-slot milling cutter 16mm, carbide T-slot cutter, slot milling cutter for CNC, carbide keyway cutter, T-slot end mill 16mm, precision carbide slotting tool
Technical FAQ & Buying Guide
Absolutely. Our CNC carbide inserts (including CNMG, WNMG, DNMG, and APMT series) are manufactured strictly adhering to international ISO/ANSI specifications. A CNMG 120408 from OYYU BEYOND will flawlessly fit any standard turning tool holder or indexable tool from major global brands like Sandvik Coromant, Kennametal, Iscar, Walter, or SECO, providing a highly cost-effective premium alternative without sacrificing tolerance or tool life.
We offer optimized CVD and PVD multi-layer coatings for different ISO material groups:
- For Carbon/Alloy Steel (ISO P): Choose our thick multi-layer CVD coated grades (e.g., Al2O3 + TiN). They provide exceptional crater wear resistance and thermal barriers during high-speed dry or wet roughing.
- For Stainless Steel (ISO M): Choose our nano-structured PVD coated grades with sharp, positive chipbreakers (like -TM or -MA). This combination prevents work hardening and effectively controls sticky chips.
The optimal cutting parameters vary depending on the workpiece hardness and operation type:
- For General Steel Turnings: Recommended cutting speed ($V_c$) ranges from 150 to 280 m/min, with a feed rate ($f$) of 0.15 to 0.45 mm/rev.
- For Stainless Steel Finishing: Recommended cutting speed ($V_c$) is 120 to 200 m/min, with a feed rate ($f$) of 0.10 to 0.25 mm/rev.Always adjust parameters based on early wear patterns: increase $V_c$ if built-up edge occurs, or reduce $V_c$ if severe flank wear is observed.
Yes, we support machine shops, distributors, and global buyers with tiered wholesale pricing and competitive volume discounts. We also provide OEM custom manufacturing solutions for tool holders and carbide inserts based on your technical drawings. Contact our team to request a quick B2B quotation.
We provide secure worldwide express shipping (via DHL, FedEx, and UPS) with specialized, vibration-proof industrial packaging to ensure tools arrive in perfect condition. In-stock items are dispatched within 24-48 hours, while custom or bulk orders typically have a stable lead time of 15-25 days.
All our cutting tools and tool holders are manufactured strictly in accordance with ISO 9001 and international industrial standards. Every batch undergoes 100% rigorous quality control testing using high-precision optical measuring equipment to ensure reliable tool life and stable performance in continuous mass production.
