20mm T-Slot Milling Cutter

$109.85 USD

30-Day Free Returns

Free Worldwide Shipping

SIZE: 20×1

20×1
20×1.5
20×2
20×2.5
20×3
20×4
20×5
20×6
Add to WishlistCompare

american expressmasterpaypalvisaapple paygoogle payshopify pay
Order in the next [totalHours] hours %M minutes to get it between and
SKU:
Description

20mm T-Slot Milling Cutter

The 20mm T-Slot Milling Cutter is a high-precision cutting tool designed for machining T-slots, keyways, and precision grooves on CNC milling centers. Manufactured from ultra-fine grain solid carbide, this tool delivers excellent wear resistance, stable performance, and long service life — even under heavy-duty cutting conditions.

Features

  • High-quality solid carbide ensures durability and precision.
  • Optimized cutting geometry minimizes chatter and vibration.
  • Excellent chip evacuation for smooth and clean slot surfaces.
  • Available with TiAlN or AlTiN coatings for longer tool life.
  • Ideal for machining T-slots, keyways, and form grooves in various materials.

Specifications

Model T-Slot Milling Cutter
Cutting Diameter (d1) 20 mm
Shank Diameter (d2) 20 mm
Cutting Width (b) 8 mm
Neck Diameter (d3) 12 mm
Overall Length (L) 90 mm
Material Solid Carbide
Coating TiAlN / AlTiN / Uncoated
Application Steel, Stainless Steel, Cast Iron, Alloy Steel

Applications

This 20mm T-Slot Milling Cutter is used for milling T-slots and keyways on workpieces, jigs, and fixtures. It provides stable cutting performance and precise dimensional accuracy, suitable for CNC machining centers and vertical milling machines.

Recommended Machines

  • CNC Vertical Milling Machines
  • High-Speed Machining Centers
  • Precision Slot Milling Equipment

Advantages

  • High rigidity for heavy-duty milling tasks.
  • Consistent dimensional accuracy in repeated production runs.
  • Longer lifespan compared to conventional HSS cutters.
  • Excellent surface finish and tight tolerances.

Why Choose Our Carbide T-Slot Cutter?

Our 20mm T-Slot Milling Cutter offers unmatched cutting performance and dimensional control. Each tool is precision-ground to ensure accuracy and reliability for industrial CNC applications. Whether you’re machining molds, fixtures, or mechanical components, this tool delivers consistent, high-quality results.

Keywords

20mm T-slot milling cutter, carbide slotting end mill, CNC T-slot cutter, keyway milling cutter, carbide T-slot end mill, slot cutting tool 20mm, precision T-slot carbide tool



Additional Information
SIZE

20×1, 20×1.5, 20×2, 20×2.5, 20×3, 20×4, 20×5, 20×6
