9mm 3 Flute Coated Carbide Chamfer Cutter 60°/90°/120° carbide end milll
Price shown is a starting point. Contact us for a precise quote based on your requirements.
BEYOND 9mm 3 Flute Coated Carbide Chamfer Cutter 60°/90°/120°
BEYOND 9mm 3 flute coated carbide chamfer cutter is a precision-engineered tool designed for CNC chamfering, deburring, and edge finishing. Its sharp cutting edges, stable structure, and high-performance coating make it ideal for machining various metals with consistent accuracy and smooth finish.
Product Features
- ✔ 3-Flute Design – Ensures smooth chip removal, stable performance, and clean chamfer edges.
- ✔ Durable Coating – Improves heat resistance, reduces tool wear, and extends tool life.
- ✔ Multi-Angle Availability – Offered in 60°, 90°, and 120° for different chamfering needs.
- ✔ Premium Carbide Material – Provides high hardness and cutting stability for precision CNC operations.
- ✔ Wide Application – Suitable for stainless steel, alloy steel, mold steel, ductile cast iron, quenched steel, and titanium alloy.
Technical Specifications
| Cutting Diameter (D1) | Angle (°) | Flute Length (L2) | Shank Diameter (D2) | Total Length (L1) |
|---|---|---|---|---|
| 9 mm | 60° / 90° / 120° | 18 mm | 9 mm | 63 mm |
Applications
- Precision chamfering, edge rounding, and deburring for CNC milling machines.
- Machining of stainless steel, mold steel, alloy steel, cast iron, and titanium alloy.
- Ideal for mold manufacturing, precision components, and metal finishing industries.
Recommended Keywords
carbide chamfer cutter, 9mm chamfer end mill, 3 flute chamfer tool, coated chamfer milling cutter, CNC chamfer cutter 60° 90° 120°, BEYOND carbide tools, precision chamfer cutter for stainless steel, titanium alloy chamfer tool, 90 degree carbide chamfer end mill, coated CNC chamfering cutter.
Advantages of BEYOND Chamfer Cutters
- ✅ High precision machining with stable tool balance and clean surface finish.
- ✅ Coating technology reduces friction and improves heat resistance for longer service life.
- ✅ Made of fine-grain carbide for rigidity and cutting performance.
- ✅ Suitable for both rough and fine chamfering applications.
Packaging & Delivery
- Each tool packed individually in a durable plastic case.
- Worldwide delivery via DHL, FedEx, or UPS.
- OEM customization and different angles available upon request.
Technical FAQ & Buying Guide
Absolutely. Our CNC carbide inserts (including CNMG, WNMG, DNMG, and APMT series) are manufactured strictly adhering to international ISO/ANSI specifications. A CNMG 120408 from OYYU BEYOND will flawlessly fit any standard turning tool holder or indexable tool from major global brands like Sandvik Coromant, Kennametal, Iscar, Walter, or SECO, providing a highly cost-effective premium alternative without sacrificing tolerance or tool life.
We offer optimized CVD and PVD multi-layer coatings for different ISO material groups:
- For Carbon/Alloy Steel (ISO P): Choose our thick multi-layer CVD coated grades (e.g., Al2O3 + TiN). They provide exceptional crater wear resistance and thermal barriers during high-speed dry or wet roughing.
- For Stainless Steel (ISO M): Choose our nano-structured PVD coated grades with sharp, positive chipbreakers (like -TM or -MA). This combination prevents work hardening and effectively controls sticky chips.
The optimal cutting parameters vary depending on the workpiece hardness and operation type:
- For General Steel Turnings: Recommended cutting speed ($V_c$) ranges from 150 to 280 m/min, with a feed rate ($f$) of 0.15 to 0.45 mm/rev.
- For Stainless Steel Finishing: Recommended cutting speed ($V_c$) is 120 to 200 m/min, with a feed rate ($f$) of 0.10 to 0.25 mm/rev.Always adjust parameters based on early wear patterns: increase $V_c$ if built-up edge occurs, or reduce $V_c$ if severe flank wear is observed.
Yes, we support machine shops, distributors, and global buyers with tiered wholesale pricing and competitive volume discounts. We also provide OEM custom manufacturing solutions for tool holders and carbide inserts based on your technical drawings. Contact our team to request a quick B2B quotation.
We provide secure worldwide express shipping (via DHL, FedEx, and UPS) with specialized, vibration-proof industrial packaging to ensure tools arrive in perfect condition. In-stock items are dispatched within 24-48 hours, while custom or bulk orders typically have a stable lead time of 15-25 days.
All our cutting tools and tool holders are manufactured strictly in accordance with ISO 9001 and international industrial standards. Every batch undergoes 100% rigorous quality control testing using high-precision optical measuring equipment to ensure reliable tool life and stable performance in continuous mass production.
