APET160508PDFR-S H1 (10pcs)

$73.33 USD
Shipping calculated at checkout.

cnchome-beyond assurance

1.Safe payments Payment methods used by many international shoppers
2.Security & privacy We respect your privacy so your personal details are safe
3.Buyer protection Get your money back if your order isn't delivered by estimated date or if you're not satisfied with your order

4.Free shipping

Add to WishlistCompare

american expressmasterpaypalvisa
Ask a Question
SKU: APET160508PDFR-S H1
Availability : In Stock Pre order Out of stock
Categories: Sumitomo Sumitomo APET
Tags: APET160508PDFR-S H1
Description
Coated Carbide:H1 Designation:APET160508PDFR-S H1
S: For Aluminum Alloy.Nose Radius RE:0.031 / 0.8.

marked inserts require modification of the cutter body. Correct the tool diameter by +0.5mm before use.
High-speed / Light:Work Material:Cast Iron,Aluminu Alloy.Hardness:250HB.
Cutting Speed vc (m/min) Min. - Optimum - Max.:70-150-180,200-300-500.
Feed Rate fz  (mm/t) Min. - Optimum - Max:
Shoulder Milling 0.05- 0.15 -0.25,Groove Milling 0.05- 0.10 -0.15,Drilling 0.05- 0.13 -0.20.Grade:ACZ310
Shoulder Milling 0.10- 0.15 -0.20 Groove Milling 0.05- 0.08 -0.10,Drilling 0.05- 0.08 -0.10.Insert Grade:DL1000
