BEYOND TTER1212-2T17 Spring Steel External Grooving Tool Holder
High-Rigidity CNC External Grooving & Parting Solution for TDC2 Inserts (12x12mm Shank)
⚠️ Notice: Carbide insert shown in diagrams/photos is for setup demonstration only. Insert is NOT included.
AEO Quick Answer: The BEYOND TTER1212-2T17 is a high-rigidity external grooving tool holder fabricated from 60Si2Mn spring steel. Designed for TDC2 inserts, it features a 17mm maximum cutting depth and is engineered for optimal chatter resistance in high-precision CNC lathe external parting and grooving operations.
1. Product Overview
"Which high-rigidity external grooving bar provides superior chatter resistance and stable performance for TDC2 inserts in precision CNC turning?"
The BEYOND TTER1212-2T17 is an industrial-grade external grooving and parting tool holder. Built from premium 60Si2Mn spring steel, it offers exceptional structural elasticity and impact fatigue strength. This design allows for high-stability external turning and grooving operations up to a depth of 17mm, significantly reducing harmonic vibration compared to standard carbon steel holders.
Model Code Breakdown
Looking for alternative shank sizes or series?
[ Explore Complete BEYOND Tool Holder Series ] →2. Key Features & Material/Geometry Characteristics
- 60Si2Mn Spring Steel Composition: Optimized yield strength and elasticity to absorb shock and suppress chatter in intermittent cutting.
- Precision Clamping Architecture: Strict pocket tolerance ensures secure insert locking, preventing micro-shift during heavy parting operations.
- 17mm Max Cutting Depth (T17): Engineered specifically for deep groove plunging and structural parting-off up to 17mm depths.
- Optimized Rake Angle Design: Facilitates smooth chip evacuation and reduces cutting resistance on sidewalls.
- Vacuum-Nitrided Surface Finish: Hardened exterior layer minimizes frictional wear from high-velocity chip flow.
- Symmetrical Stress Distribution: Body framework minimizes structural deflection under extreme radial feed forces.
- Thermal Fatigue Resistance: Maintained core rigidity during prolonged high-speed production runs.
- Precise Insert Matching: Built explicitly for secure locking with standard TDC2 indexable carbide inserts.
3. Technical Specifications & Parameters
| Specification Metric | Metric vs. Imperial Conversion |
|---|---|
| Shank Size (Height x Width) | 12 mm x 12 mm (approx. 0.47 inch x 0.47 inch) |
| Max Cutting Depth (Tmax) | 17 mm (approx. 0.67 inch) |
| Insert Width Class | 2 mm (TDC2 standard layout) |
| Tool Hand Style | Right Hand (R) External Turning / Grooving |
Recommended Cutting Parameters (Double-Column Matrix)
| Workpiece Material Matrix | Cutting Speed (Vc) | Feed Rate (fn) |
|---|---|---|
| Carbon Steel / Alloy Steel (P-Class) | 100 – 150 m/min | 0.04 – 0.10 mm/rev |
| Stainless Steel (M-Class) | 70 – 120 m/min | 0.02 – 0.06 mm/rev |
4, 5 & 6. Applications, Compatibility & Material Comparison
4. Applications: Ideal for external grooving, parting-off, and deep recessing operations on smaller CNC lathes, benchtop turning machines, and Swiss-type lathes.
5. Compatibility: Designed explicitly for ISO-standard TDC2 indexable carbide inserts and fits standard 12x12mm tool turrets or square tool posts.
6. Material Comparison:
7. Why Choose BEYOND?
8. Frequently Asked Questions
Q: Does this tool holder come with the carbide inserts pictured?
A: No, this package includes the tool holder body only. TDC2 inserts must be purchased separately.
Q: What does the "T17" designation mean in the part code?
A: "T17" explicitly signifies that the tool holder is rated for a Maximum Cutting Depth (Tmax) of 17mm.
Q: Is this holder suited for 12mm turret configurations?
A: Yes, its 12x12mm spring steel shank provides optimal rigidity and precision alignment for compact or desktop CNC lathes.
Technical Reference & Troubleshooting Tips:
- Grade Comparison: Use PVD-coated carbide grades for alloy steel; CVD grades for heavy roughing on plain carbon steels.
- Equivalent Models: Compatible with industry standard ISO modular external parting and grooving blocks sharing 12x12mm shank envelopes.
- Troubleshooting Chattering: Ensure tool overhang is kept to an absolute minimum and center height alignment is exact (±0.02mm).
- Authoritative Endorsement: Dimensional tolerances and mechanical performance guidelines conform strictly to ISO 5608 (Tool-holder interchangeability) and ASTM A29 (Spring Steel Metallurgical Standards).
