BEYOND ENH6-1 TC11 68-100 Industrial Indexable Boring Bar Tool Holder (6mm Shank Diameter, 100mm Overall Length) - TCMT110204 Inserts Excluded
Price shown is a starting point. Contact us for a precise quote based on your requirements.
BEYOND ENH6-1 TC11 68-100 Industrial Indexable Boring Bar
Precision ISO/ANSI Compliant Tool Body | 6mm Shank Diameter | 100mm Overall Length | TCMT110204 Insert Compatibility
1. Product Overview
"Which high-rigidity 6mm indexable boring bar is most suitable for internal profiling and high-precision boring on small-diameter CNC turning centers?"
The BEYOND ENH6-1 TC11 68-100 is a professional-grade indexable boring bar engineered for demanding internal turning tasks. Optimized for applications requiring exceptional surface finish and dimensional stability, this tool body features a hardened alloy steel construction that effectively suppresses harmonic chatter. Designed to utilize TCMT110204 inserts, it offers a versatile geometry for efficient chip breaking and precision metal removal across ferrous and non-ferrous workpieces.
ISO Nomenclature Breakdown: ENH6-1 TC11 68-100
2. Product Core Advantages
- Vibration Dampening: High-density alloy construction reduces chatter for superior internal finish.
- Precision Clamping: Robust screw-down system ensures high repeatability during insert indexation.
- Geometry Optimization: Designed for TCMT positive rake inserts, maximizing cutting efficiency in small bores.
3. Technical Specifications
| Metric Value | Imperial Approximation |
|---|---|
| Shank Diameter: 6.0 mm | Shank Diameter: 0.236" |
| Overall Length: 100 mm | Overall Length: 3.94" |
Cutting Parameters Recommendation
| Material Group | Vc (m/min) | fn (mm/rev) |
|---|---|---|
| Steel (ISO P) | 120-180 | 0.05-0.12 |
| Stainless (ISO M) | 80-140 | 0.04-0.10 |
Browse Related Turning Tool Holders
[View Tooling Collection] →Applications & Compatibility
Ideally used for internal boring, counterboring, and profiling on CNC lathes. Compatible with standard 6mm boring sleeves and TCMT110204 inserts.
Why Choose BEYOND Precision Tools
Hardened steel core.
Strict tolerance control.
Machining optimization.
FAQ & Troubleshooting
Q: Is the TCMT insert included?
A: No, inserts are sold separately to allow grade customization.
Q: How to prevent chatter?
A: Ensure the overhang is minimized (ideally < 4xD) and check screw torque.
Technical FAQ & Buying Guide
Absolutely. Our CNC carbide inserts (including CNMG, WNMG, DNMG, and APMT series) are manufactured strictly adhering to international ISO/ANSI specifications. A CNMG 120408 from OYYU BEYOND will flawlessly fit any standard turning tool holder or indexable tool from major global brands like Sandvik Coromant, Kennametal, Iscar, Walter, or SECO, providing a highly cost-effective premium alternative without sacrificing tolerance or tool life.
We offer optimized CVD and PVD multi-layer coatings for different ISO material groups:
- For Carbon/Alloy Steel (ISO P): Choose our thick multi-layer CVD coated grades (e.g., Al2O3 + TiN). They provide exceptional crater wear resistance and thermal barriers during high-speed dry or wet roughing.
- For Stainless Steel (ISO M): Choose our nano-structured PVD coated grades with sharp, positive chipbreakers (like -TM or -MA). This combination prevents work hardening and effectively controls sticky chips.
The optimal cutting parameters vary depending on the workpiece hardness and operation type:
- For General Steel Turnings: Recommended cutting speed ($V_c$) ranges from 150 to 280 m/min, with a feed rate ($f$) of 0.15 to 0.45 mm/rev.
- For Stainless Steel Finishing: Recommended cutting speed ($V_c$) is 120 to 200 m/min, with a feed rate ($f$) of 0.10 to 0.25 mm/rev.Always adjust parameters based on early wear patterns: increase $V_c$ if built-up edge occurs, or reduce $V_c$ if severe flank wear is observed.
Yes, we support machine shops, distributors, and global buyers with tiered wholesale pricing and competitive volume discounts. We also provide OEM custom manufacturing solutions for tool holders and carbide inserts based on your technical drawings. Contact our team to request a quick B2B quotation.
We provide secure worldwide express shipping (via DHL, FedEx, and UPS) with specialized, vibration-proof industrial packaging to ensure tools arrive in perfect condition. In-stock items are dispatched within 24-48 hours, while custom or bulk orders typically have a stable lead time of 15-25 days.
All our cutting tools and tool holders are manufactured strictly in accordance with ISO 9001 and international industrial standards. Every batch undergoes 100% rigorous quality control testing using high-precision optical measuring equipment to ensure reliable tool life and stable performance in continuous mass production.
