R3 (6mm) Steel Chamfer carbide end milll
Price shown is a starting point. Contact us for a precise quote based on your requirements.
BEYOND R3 (6mm) Steel Chamfer End Mill – Arc Type Up & Down Chamfer Cutter
The BEYOND R3 (6mm) Steel Chamfer End Mill is designed for precise edge finishing, chamfering, and deburring of steel parts in CNC machining. Its arc-type up & down blade geometry allows simultaneous top and bottom chamfering, reducing setup time and achieving a smoother finish on workpiece edges.
Key Features
- Cutting Diameter (d1): 6mm
- Chamfer Radius (R): R3
- Shank Diameter (d2): 6mm
- Overall Length (L): 50mm
- Material: Premium tungsten carbide for excellent strength and durability.
- Design: Arc-shaped cutting edges for dual-side chamfering (up & down).
- Coating: TiAlN/AlTiN coating for superior oxidation and heat resistance.
- Applications: Suitable for carbon steel, alloy steel, die steel, pre-hardened steel.
- Tool Type: CNC chamfering and edge-finishing tool.
Technical Specifications
| Model | Radius (R) | Cutting Diameter (d1) | Shank Diameter (d2) | Overall Length (L) | Material |
|---|---|---|---|---|---|
| R3-6MM | R3 | 6mm | 6mm | 50mm | Tungsten Carbide |
Advantages
- Performs dual chamfering in a single pass, improving efficiency.
- Arc geometry minimizes burrs and ensures perfect edge transitions.
- Provides high surface smoothness for precise machining results.
- Maintains cutting stability and reduces vibration on high-speed CNC machines.
- Durable carbide material extends tool lifespan under continuous use.
Recommended Cutting Parameters
- Cutting Speed (Vc): 100–180 m/min
- Feed per Tooth (fz): 0.02–0.06 mm/tooth
- Depth of Cut (ap): 0.4–1.0 mm
Applications
The R3 (6mm) Steel Chamfer End Mill is ideal for chamfering, deburring, and rounding steel parts in mold manufacturing, die finishing, and mechanical component machining. It provides consistent results for professional CNC metalworking operations.
Why Choose BEYOND?
BEYOND specializes in precision CNC cutting tools that deliver performance and durability. Every product is manufactured using ultra-fine carbide and advanced coating technology, ensuring reliability and superior surface results in industrial applications.
Technical FAQ & Buying Guide
Absolutely. Our CNC carbide inserts (including CNMG, WNMG, DNMG, and APMT series) are manufactured strictly adhering to international ISO/ANSI specifications. A CNMG 120408 from OYYU BEYOND will flawlessly fit any standard turning tool holder or indexable tool from major global brands like Sandvik Coromant, Kennametal, Iscar, Walter, or SECO, providing a highly cost-effective premium alternative without sacrificing tolerance or tool life.
We offer optimized CVD and PVD multi-layer coatings for different ISO material groups:
- For Carbon/Alloy Steel (ISO P): Choose our thick multi-layer CVD coated grades (e.g., Al2O3 + TiN). They provide exceptional crater wear resistance and thermal barriers during high-speed dry or wet roughing.
- For Stainless Steel (ISO M): Choose our nano-structured PVD coated grades with sharp, positive chipbreakers (like -TM or -MA). This combination prevents work hardening and effectively controls sticky chips.
The optimal cutting parameters vary depending on the workpiece hardness and operation type:
- For General Steel Turnings: Recommended cutting speed ($V_c$) ranges from 150 to 280 m/min, with a feed rate ($f$) of 0.15 to 0.45 mm/rev.
- For Stainless Steel Finishing: Recommended cutting speed ($V_c$) is 120 to 200 m/min, with a feed rate ($f$) of 0.10 to 0.25 mm/rev.Always adjust parameters based on early wear patterns: increase $V_c$ if built-up edge occurs, or reduce $V_c$ if severe flank wear is observed.
Yes, we support machine shops, distributors, and global buyers with tiered wholesale pricing and competitive volume discounts. We also provide OEM custom manufacturing solutions for tool holders and carbide inserts based on your technical drawings. Contact our team to request a quick B2B quotation.
We provide secure worldwide express shipping (via DHL, FedEx, and UPS) with specialized, vibration-proof industrial packaging to ensure tools arrive in perfect condition. In-stock items are dispatched within 24-48 hours, while custom or bulk orders typically have a stable lead time of 15-25 days.
All our cutting tools and tool holders are manufactured strictly in accordance with ISO 9001 and international industrial standards. Every batch undergoes 100% rigorous quality control testing using high-precision optical measuring equipment to ensure reliable tool life and stable performance in continuous mass production.
