SUMITOMO WDXT052504-G ACP300 Indexable Milling Insert for Steel & Stainless Steel (WDXT 052504 / 0.197" Cutting Diameter Equivalent)
Free shipping on all orders.
Check compatibility: Confirm the model and dimensions before ordering.
Need help choosing? Contact us before ordering.
💰 Bulk savings 2-9 pcs · 6% OFF | 10+ pcs · 12% OFF
SUMITOMO WDXT052504-G ACP300 PVD Coated Carbide Indexable Milling & Drilling Insert
1. Product Overview
"Which indexable carbide insert grade and chipbreaker design are best suited for structural steel roughing, high-feed pocket milling, and indexable drilling where thermal shock resistance and chip jamming prevention are critical?"
The SUMITOMO WDXT052504-G ACP300 is a high-performance, multi-functional indexable carbide insert meticulously designed for high-feed slotting, square shoulder milling, pocketing, and core drilling operations. Engineered for optimal execution within carbon steel, alloy steel, and stainless steel families (ISO P20–P40 and M20–M40 categories), this insert features Sumitomo's breakthrough ACP300 PVD Super-FF (Fine-Film) Coating. By combining an ultra-dense, nano-structured TiAlN multi-layer architecture with a highly specialized shock-resistant submicron carbide substrate, the ACP300 grade delivers unparalleled resistance to micro-chipping, thermal cracking, and built-up edge (BUE) formation. Integrated with the -G Type General-Purpose Chipbreaker, it features an optimized positive rake angle that significantly dampens tool vibration, curtails cutting resistance, and guarantees rapid, seamless chip evacuation during aggressive metal removal rates (MRR).
2. Product Key Features
- Super-FF TiAlN PVD Coating Matrix: Employs ultra-smooth, high-density multi-layered PVD technology that acts as a robust thermal barrier, drastically minimizing crater wear and plastic deformation under high-speed dry or wet machining.
- Heavy Mechanical Impact Resistance: Engineered with a premium high-toughness carbide substrate specifically formulated to withstand harsh interrupted cutting forces and continuous thermal shock cycle strains typical in multi-flute indexable drilling.
- Advanced -G Chip Control Geometry: Features a variable positive rake profile that optimizes chip deformation, forcing rapid chip fragmentation and preventing disastrous chip wrapping in deep slotting matrices.
- Rigid Dimensional Edge Accuracy: Fabricated under strict ISO/ANSI tolerances to ensure minimal radial/axial runout deviation, yielding superior workpiece surface finishes and prolonged toolholder pocket lifespans.
3. Technical Specifications & Dimension Matrix
🔍 ISO / ANSI Industrial Nomenclature Decoding Matrix
| Dimension Parameter | Metric Specification (ISO) | Imperial Equivalent Benchmark |
|---|---|---|
| Major Insert Length / Size | 5.5 mm | ~0.217 in |
| Insert Thickness / Width | 2.5 mm | ~0.098 in |
| Corner Radius (re) | 0.4 mm | 0.016 in (~1/64") |
| Application Type | Indexable Milling & Drilling | Indexable Drill / Indexable Cutter Insert |
📊 Recommended Technical Cutting Parameters
| Workpiece Material Category | Cutting Speed (vc) | Feed Rate per Tooth (fz) / Depth |
|---|---|---|
| Carbon & Alloy Steels (AISI 1045 / 4140 / 4340) | 160 - 260 m/min (525 - 850 SFM) | 0.04 - 0.12 mm/tooth (0.0015 - 0.005 ipt) ap: 0.3 - 2.5 mm (0.012 - 0.098 in) |
| Stainless Steels (AISI 304 / 316 / Duplex) | 100 - 180 m/min (330 - 590 SFM) | 0.03 - 0.10 mm/tooth (0.0012 - 0.004 ipt) ap: 0.2 - 2.0 mm (0.008 - 0.078 in) |
This WDXT052504 insert matrix requires compatible indexable drills or high-feed indexable milling cutter bodies designed specifically for WDXT 05-series pockets.
Browse Matching WDX Indexable Drills & Milling Bodies →4. Product Application Scenarios
The ACP300 PVD coated milling grade provides outstanding metal removal efficiency across rigorous industrial sectors:
5. Toolholder & Equipment Compatibility
Strictly compliant with indexable pocket seat standards, this insert integrates seamlessly into global standard milling and drilling systems:
- Cutter Bodies: Fits all premium Sumitomo WDX series indexable drills and modular high-feed face milling cutter assemblies requiring an 05-size WDXT pocket configuration.
- CNC Machinery Systems: Fully optimized for precise control on high-rigidity CNC machining equipment (Doosan, Mazak, DMG Mori, Makino, Haas) featuring advanced flood or high-pressure through-spindle coolant networks.
6. Industrial Grade Comparison Matrix
| Brand | Equivalent Grade Reference | Application Range | Coating Technology |
|---|---|---|---|
| SUMITOMO | ACP300 (Target) | ISO P20-P40 / M20-M40 / General Steel & Stainless Milling | Multi-Layered Nano-Structured TiAlN PVD Coating |
| Sandvik Coromant | S40T / 4330 | ISO P25 - P40 / Steel Roughing & Drilling | Inveio® CVD / Tough PVD alternative coatings |
| Kennametal | KCP25B / KCU25 | ISO P20 - P40 / Universal Steel Milling Matrix | Advanced PVD multilayer coating architecture |
| Iscar | IC808 / IC830 | ISO P/M Interrupted Cutting & Drilling | SUMO TEC AlTiN PVD tough barrier system |
7. Why Choose Us & Verified Global Performance Evaluations
Real-world machine shop data proving reliable edge toughness and high metal removal rates under rigorous milling tasks:
"We switched to WDXT052504-G ACP300 for our high-feed pocket milling program on 4140 pre-hardened steel blocks. The edge toughness is unbelievable. No corner chipping under interrupted cuts, and tool life increased by roughly 45% compared to our previous European brand."
"Absolut erstklassige Standzeit beim Bohren von Edelstahlplatten (1.4301). Der -G Spanbrecher bricht die Späne extrem zuverlässig kurz, wodurch Kratzer an der Bohrungswand vermieden werden. ACP300 bleibt unsere erste Wahl für P- und M-Materialien."
"Inserto eccellente su centri di lavoro Haas per fresatura ad alta avanzamento. Il rivestimento PVD resiste egregiamente allo shock termico generato dall'emulsione. Molto stabile."
"住友電工のWDXT052504-G ACP300は金型枠の荒加工で非常に安定しています。刃先強度のバランスが良く、他社品で頻発していた突発的なチッピングが皆無になりました。サイクルタイム短縮に貢献しています。"
8. Technical Machining FAQ
Q: What specific cutting operations are best suited for the WDXT052504-G insert?
A: This insert is specifically engineered for indexable drills (WDX series) and high-feed indexable milling cutters, excelling in heavy roughing, pocketing, slotting, and helical interpolation across steel and stainless steel materials.
Q: How does the ACP300 PVD coating perform under wet versus dry machining conditions?
A: The ACP300 grade is uniquely optimized for high thermal variations. While it performs perfectly dry under high speeds, its advanced TiAlN coating layer structure shows elite resistance to thermal stress cracks during heavy wet milling operations with continuous emulsified flood coolant.
Q: What is the purpose of the -G chipbreaker designation?
A: The -G chipbreaker provides a balanced positive geometry that lowers cutting resistance and ensures smooth chip curling across general steel and alloy milling operations, preventing chip packing inside confined pockets.
💡 Technical Grade Comparison & Troubleshooting Guide
Workpiece Material Matrix (ISO Classifications): Primary application domain covers ISO P20 to P40 and M20 to M40 parameters. Explicitly optimized for structural carbon steels (e.g., S45C), alloy steels (e.g., SCM440, 4140), and austenitic stainless steels (e.g., 304, 316) under stable toolholding conditions.
Machining Troubleshooting Guide: If rapid flank wear or edge deformation occurs, consider reducing the cutting speed ($v_c$) or optimizing the coolant delivery. If micro-chipping or heavy edge fracturing is observed along the peripheral corner, verify toolholder pocket cleanliness, check for spindle runout, and ensure that the feed rate per tooth ($f_z$) matches recommended structural limits.
Authorized Reference Documentation & Endorsements: Dimensional configurations, pocket seating tolerances, and naming structures fully comply with international industrial standards blueprints. Mechanical strength thresholds, thermal crack criteria, and wear tolerances are cross-referenced from verified test catalogs published by Sumitomo Electric Hardmetal Corp.
Need Help With Sumitomo Inserts?
Looking for a Sumitomo equivalent, alternative grade, or sample catalog? Our CNC specialists have helped 50+ manufacturers in aerospace, automotive, and medical machining source the right tooling at 30–50% lower cost than OEM prices.
This Sumitomo insert is in stock. 24-hour quote response. ISO 9001 certified. Ships from Hangzhou in 3–7 days.
Technical FAQ & Buying Guide
When choosing CNC cutting tools, check the full model code, dimensions, grade and selected variant before ordering. Do not rely on the product image alone.
For carbide inserts, tool holders, drills and end mills, compare the mounting dimensions, connection type and manufacturer's specifications with your holder or machine. If you are unsure, share your existing part number and machining application with us before ordering.
Check the product listing for the selling unit, pack quantity and included components. If it is unclear whether the price is per piece or per pack, or whether a tool body and inserts are sold separately, contact us before purchasing.
Select cutting speed, feed rate and depth of cut using the relevant manufacturer's recommendations for your tool model, workpiece material, machine conditions and coolant method. The same settings are not suitable for every product or application.
Our automatic quantity discount is 6% off for 2–9 items and 12% off for 10 or more items, based on the total product quantity in the cart. Other offers may not combine with this discount; check the applicable offer conditions.
According to our shipping policy, orders are typically processed and shipped within 1–3 business days after confirmation. Delivery generally takes 5–20 business days, depending on your destination and shipping method. Customs clearance or unforeseen delays may affect delivery times. A tracking number is sent by email after shipment.
