Milling Insert ZCC.CT

PVD Coating:YBG302,Designation:LNKT1506EN-ZR YBG302 Turning Milling tool Dimension (mm):L:15.875,I.W:14,S:6.35,ød:4.6 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Unfavorable Machining Condition

CVD Coating:YBC302,Designation:MPHT120408-DM YBC302 Turning Milling tool Dimension (mm):ØI.C:12.7,L:12.7,s:4.76,ød:5.56,r:0.8 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition DM:Main chip breaker for medium machining with continuous or interrupted cut of steel and stainless...

CVD Coating:YBM253,Designation:MPHT080305-DM YBM253 Turning Milling tool Dimension (mm):ØI.C:8.3,L:8.3,s:3.18,ød:3.4,r:0.5 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition DM:Main chip breaker for medium machining with continuous or interrupted cut of steel and stainless...

CVD Coating:YBM251,Designation:MPHT080305-DM YBM251 Turning Milling tool Dimension (mm):ØI.C:8.3,L:8.3,s:3.18,ød:3.4,r:0.5 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition DM:Main chip breaker for medium machining with continuous or interrupted cut of steel and stainless...

PVD Coating:YBG302,Designation:MPHT080305-DM YBG302 Turning Milling tool Dimension (mm):ØI.C:8.3,L:8.3,s:3.18,ød:3.4,r:0.5 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Unfavorable Machining Condition DM:Main chip breaker for medium machining with continuous or interrupted cut of steel and stainless steel....

PVD Coating:YBG205 ,Designation:MPHT080305-DM YBG205  Turning Milling tool Dimension (mm):ØI.C:8.3,L:8.3,s:3.18,ød:3.4,r:0.5 Workpiece Material:Steel:Ideal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, DM:Main chip breaker for medium machining with continuous or interrupted cut of...

CVD Coating:YBD252,Designation:MPHT080305-DM YBD252 Turning Milling tool Dimension (mm):ØI.C:8.3,L:8.3,s:3.18,ød:3.4,r:0.5 Workpiece Material:Cast iron:Unfavorable Machining Condition DM:Main chip breaker for medium machining with continuous or interrupted cut of steel and stainless steel.

CVD Coating:YBM253,Designation:MPHT060304-DM YBM253 Turning Milling tool Dimension (mm):ØI.C:6.35,L:6.35,s:3.18,ød:2.8,r:0.4 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition DM:Main chip breaker for medium machining with continuous or interrupted cut of steel and stainless...

PVD Coating:YBG302,Designation:MPHT060304-DM YBG302 Turning Milling tool Dimension (mm):ØI.C:6.35,L:6.35,s:3.18,ød:2.8,r:0.4 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Unfavorable Machining Condition DM:Main chip breaker for medium machining with continuous or interrupted cut of steel and stainless steel....

CVD Coating:YBD252,Designation:MPHT060304-DM YBD252 Turning Milling tool Dimension (mm):ØI.C:6.35,L:6.35,s:3.18,ød:2.8,r:0.4 Workpiece Material:Cast iron:Unfavorable Machining Condition DM:Main chip breaker for medium machining with continuous or interrupted cut of steel and stainless steel.

ZCC.CT MPHT060304-DM YBC302 Carbide Milling Inserts (MPHT 21.51 DM Chipbreaker) Heavy-Duty 90° Square Shoulder Milling Inserts | ISO MPHT060304 (ANSI MPHT 21.51) | YBC302 CVD Coated Grade for Medium-to-Heavy Steel...

ZCC.CT ONHU060408-PF YBC302 Milling Insert 16-Edge Octagonal Efficiency for Premium Steel Face Milling Product Overview "Which milling insert provides the lowest cost-per-edge while maintaining a high-feed rate in carbon and...

CVD Coating:YBC302,Designation:PNEG110512R-PR YBC302 Turning Milling tool Dimension (mm):L:7.5,ØI.C:15.875,S:5.56,ød:4.64,bs:1.4,ap:7.5 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition

CVD Coating:YBC302,Designation:PNEG110512R-PM YBC302 Turning Milling tool Dimension (mm):L:7.5,ØI.C:15.875,S:5.56,ød:4.64,bs:1.4,ap:7.5 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition

CVD Coating:YBC302,Designation:PNEG110512R-PF YBC302 Turning Milling tool Dimension (mm):L:7.5,ØI.C:15.875,S:5.56,ød:4.64,bs:1.4,ap:7.5 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition

CVD Coating:YBD152,Designation:PNEG110512R-CR YBD152 Turning Milling tool Dimension (mm):L:5.4,ØI.C:15.875,S:5.56,ød:4.64,bs:1.6,ap:5 Workpiece Material:Cast iron:Unfavorable Machining Condition

CVD Coating:YBD152,Designation:PNEG110512R-CR YBD152 Turning Milling tool Dimension (mm):L:5.4,ØI.C:15.875,S:5.56,ød:4.64,bs:1.6,ap:5 Workpiece Material:Cast iron:Normal Machining Condition

CVD Coating:YBM253,Designation:PNEG110512R-CM YBM253 Turning Milling tool Dimension (mm):L:5.4,ØI.C:15.875,S:5.56,ød:4.64,bs:1.6,ap:5 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition

CVD Coating:YBD152,Designation:PNEG110512R-CM YBD152 Turning Milling tool Dimension (mm):L:5.4,ØI.C:15.875,S:5.56,ød:4.64,bs:1.6,ap:5 Workpiece Material:Cast iron:Normal Machining Condition

CVD Coating:YBD152,Designation:PNEG110512R-CF YBD152 Turning Milling tool Dimension (mm):L:5.4,ØI.C:15.875,S:5.56,ød:4.64,bs:1.6,ap:5 Workpiece Material:Cast iron:Normal Machining Condition

CVD Coating:YBM253,Designation:ONHU08T624R-GM YBM253 Turning Milling tool Dimension (mm):L:6.38,ØI.C:20.2,S:6.3,ød:5.3,r:2.4 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition

CVD Coating:YBD152,Designation:ONHU08T624R-GM YBD152 Turning Milling tool Dimension (mm):L:6.38,ØI.C:20.2,S:6.3,ød:5.3,r:2.4 Workpiece Material:Cast iron:Normal Machining Condition

CVD Coating:YBG202,Designation:ONHU08T508-PM YBM351 Turning Milling tool Dimension (mm):L:8.37,ØI.C:20.2,S:5.77,ød:5.3,r:0.83 Workpiece Material:Steel:Unfavorable Machining Condition,Stainless Steel:Unfavorable Machining Condition PM:Universal chip breaker with stable cutting edge. Suitable for medium machining also with interrupted cut especially...

CVD Coating:YBM253,Designation:ONHU08T508-PF YBM253 Turning Milling tool Dimension (mm):L:8.37,ØI.C:20.2,S:5.77,ød:5.3,r:0.83 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition
