PVD Coating:YBG205,Designation:ANGX110508PNR-GM YBG205 Dimension (mm):L:11.85,W:8.4,S:5.7,ød:3.5,r:0.8 Workpiece Material:Steel:Ideal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition,

CVD Coating:YBM253,Designation:ANGX110508PNR-GM YBM253 Dimension (mm):L:11.85,W:8.4,S:5.7,ød:3.5,r:0.8 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition

PVD Coating:YB9320,Designation:ANGX150608PNR-GM YB9320 Dimension (mm):L:15.43,W:11.0,S:7.3,ød:4.4,r:0.8 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition,

CVD Coating:YBD252,Designation:ANGX150608PNR-GM YBD252 Dimension (mm):L:15.43,W:11.0,S:7.3,ød:4.4,r:0.8 Workpiece Material:Cast iron:Unfavorable Machining Condition

CVD Coating:YBD152,Designation:ANGX150616PNR-GM YBD152 Dimension (mm):L:15.43,W:11.0,S:7.3,ød:4.4,r:1.6 Workpiece Material:Cast iron:Normal Machining Condition

CVD Coating:YBD152,Designation:ANGX150616PNR-GM YBD252 Dimension (mm):L:15.43,W:11.0,S:7.3,ød:4.4,r:1.6 Workpiece Material:Cast iron:Unfavorable Machining Condition

CVD Coating:YBM253,Designation:ANGX150616PNR-GM YBM253 Dimension (mm):L:15.43,W:11.0,S:7.3,ød:4.4,r:1.6 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition

Specifications:   Designation: AP16 400R-100-22-6T-AL Blade material:Coated  Inner hole : 100mm Diameter : 22mm Number of blades : 6 Applicable blade : SEKT1204 Package Includes: A milling cutter (not include blade)...

Coated Carbide:H1 Designation:APET103504PDFR-S H1 S: For Aluminum Alloy.Nose Radius RE:0.016 / 0.4. High-speed / Light:Work Material:Cast Iron,Aluminu Alloy.Hardness:250HB. Cutting Speed vc (m/min) Min. - Optimum - Max.:70-150-180,200-300-500. Feed Rate fz...

Coated Carbide:H1 Designation:APET160508PDFR-S H1 S: For Aluminum Alloy.Nose Radius RE:0.031 / 0.8.   marked inserts require modification of the cutter body. Correct the tool diameter by +0.5mm before use. High-speed...

APKT11T304-LH YD101 Carbide Milling Insert – Ultra-Fine Grain Uncoated Grade for Non-Ferrous Precision Milling ZCC.CT  |  ISO APKT  |  Ultra-Fine Grain Uncoated YD101  |  LH Chipbreaker  |  Corner Radius R0.4...

PVD Coating:YB9320,Designation:APKT11T308-APM YB9320 Dimension (mm):L:12.24,I.W:6.64,S:3.6,ød:2.8,r:0.8 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, Turning Milling tools

PVD Coating:YB9320,Designation:APKT11T312-APM YB9320 Dimension (mm):L:12.24,I.W:6.64,S:3.6,ød:2.8,r:1.2 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, Turning Milling tools

PVD Coating:YB9320,Designation:APKT11T320-APM YB9320 Dimension (mm):L:12.24,I.W:6.64,S:3.6,ød:2.8,r:2.0 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, Turning Milling tools

APKT150412R YBM351 CVD Carbide Milling Insert – High-Toughness Grade for Steel & Stainless Steel in Unfavorable Conditions ZCC.CT  |  ISO APKT  |  CVD Multi-Layer Coating YBM351  |  Right-Hand (R)  | ...

PVD Coating:YB9320,Designation:APKT160408-APM YB9320 Dimension (mm):L:17.877,I.W:9.33,S:5.76,ød:4.4,r:0.8 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, Turning Milling tools

PVD Coating:YB9320,Designation:APKT160416-APM YB9320  Dimension (mm):L:17.877,I.W:9.33,S:5.76,ød:4.4,r:1.6 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, Turning Milling tools

PVD Coating:YB9320,Designation:APKT160420-APM YB9320 Dimension (mm):L:17.877,I.W:9.33,S:5.76,ød:4.4,r:2.0 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, Turning Milling tools

PVD Coating:YB9320,Designation:APKT160424-APM YB9320 Dimension (mm):L:17.877,I.W:9.33,S:5.76,ød:4.4,r:2.4 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, Turning Milling tools

PVD Coating:YB9320,Designation:APKT160430-APM YB9320 Dimension (mm):L:17.877,I.W:9.33,S:5.76,ød:4.4,r:3.0 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, Turning Milling tools

Coated Carbide:ACZ330 Designation:APMT103504PDER-H ACZ330 Nose Radius RE:0.016 / 0.4.-H: Strong Edge Type. General-purpose:P:Work Material:Carbon Steel.Hardness:180 to 280 HB Cutting Speed vc (m/min) Min. - Optimum - Max.:80- 120 -160. Feed...

Coated Carbide:ACZ330 Designation:APMT103508PDER-H ACZ330 Nose Radius RE:0.032 / 0.8.-H: Strong Edge Type. General-purpose: P:Work Material:Carbon Steel.Hardness:180 to 280 HB Cutting Speed vc (m/min) Min. - Optimum - Max.:80- 120 -160....

PVD Coating:YBG102,Designation:APMT1135PDR YBG102 Dimension (mm):L:11.25,I.W:6.2,S:3.5,ød:2.8,r:0.8 Workpiece Material:Cast iron:Ideal Machining Condition,Heat-resistant steel:Ideal Machining Condition Turning Milling tools

PVD Coating:YBG205,Designation:APMT1135PDR YBG205 Dimension (mm):L:11.25,I.W:6.2,S:3.5,ød:2.8,r:0.8 Workpiece Material:Steel:Ideal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, Turning Milling tools

PVD Coating:YBG302,Designation:APMT1135PDR YBG302 Dimension (mm):L:11.25,I.W:6.2,S:3.5,ød:2.8,r:0.8 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Unfavorable Machining Condition Turning Milling tools

PVD Coating:YBG202,Designation:APMT160408PDER YBG202  Dimension (mm):L:17.25,I.W:9.25,S:4.76,ød:4.4,r:0.8 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition Turning Milling tools

PVD Coating:YBG205,Designation:APMT160408PDER YBG205 Dimension (mm):L:17.25,I.W:9.25,S:4.76,ød:4.4,r:0.8 Workpiece Material:Steel:Ideal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, Turning Milling tools

PVD Coating:YBG302,Designation:APMT160408PDER YBG302  Dimension (mm):L:17.25,I.W:9.25,S:4.76,ød:4.4,r:0.8 Workpiece Material:Steel:Normal Machining Condition,Stainless Steel:Unfavorable Machining Condition Turning Milling tools

PVD Coating:YBG202,Designation:APMT160416PDER-DR YBG202   Dimension (mm):L:17.25,I.W:9.25,S:4.76,ød:4.4,r:1.6 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition Turning Milling tools

PVD Coating:YBG205,Designation:APMT160416PDER-DR YBG205 Dimension (mm):L:17.25,I.W:9.25,S:4.76,ød:4.4,r:1.6 Workpiece Material:Steel:Ideal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition, Turning Milling tools

PVD Coating:YBG202,Designation:APMT160430PDER-DR YBG202  Dimension (mm):L:17.25,I.W:9.25,S:4.76,ød:4.4,r:3.0 Workpiece  Material:Steel:Normal Machining Condition,Stainless Steel:Normal Machining Condition,Heat-resistant steel:Normal Machining Condition Turning Milling tools

Coated Carbide:ACZ310 Designation:APMT160508PDER-H ACZ310 S: For Aluminum Alloy.Nose Radius RE:0.031 / 0.8.   marked inserts require modification of the cutter body. Correct the tool diameter by +0.5mm before use.  ...

Coated Carbide:ACZ330 Designation:APMT160508PDER-H ACZ330 H:Strong Edge Type..Nose Radius RE:0.031 / 0.8.   marked inserts require modification of the cutter body. Correct the tool diameter by +0.5mm before use. General-purpose:P:Work Material:Carbon...

Coated Carbide:ACZ330 Designation:APMT160520PDER-H ACZ330 H:Strong Edge Type..Nose Radius RE:0.079 / 2.0.   marked inserts require modification of the cutter body. Correct the tool diameter by +0.5mm before use. General-purpose:P:Work Material:Carbon...

Carbide:H1,Designation:AXET123504PEFR-S H1 Nose Radius RE:016" / 0.4,S:For Aluminum Alloy. High-speed / Light:K,N

Carbide:H1,Designation:AXET123504PEFR-S H1 Nose Radius RE:032" / 0.8,S:For Aluminum Alloy. High-speed / Light:K,N

DLC:DL1000 ,Designation:AXET170504PEFR-S DL1000 Nose Radius RE:.0.16, High-speed / Light:N General-purpose:N

Carbide:H1,Designation:AXET170504PEFR-S H1  Nose Radius RE:.0.16, High-speed / Light:K,N

Carbide:H1,Designation:AXET170508PEFR-S H1 Nose Radius RE:.0.31, High-speed / Light:N General-purpose:N

Coated Carbide:ACP200 ,Designation:AXMT123504PEER-G ACP200 Nose Radius RE:.016" / 0.4,Wiper Facet Length wpr:.047" / 1.2 G:General-purpose, General-purpose:P,M Roughing:P,M

Coated Carbide:ACP200 ,Designation:AXMT123504PEER-H ACP200  Nose Radius RE:.016" / 0.4,Wiper Facet Length wpr:.047" / 1.2 -H: Strong Edge General-purpose:P,M Roughing:P,M

Coated Carbide:ACK200 ,Designation:AXMT123508PEER-G ACK200 Nose Radius RE:.032" / 0.8,Wiper Facet Length wpr:.031" / .8 G:General-purpose, High-speed / Light:K General-purpose:K

Coated Carbide:ACP200,Designation:AXMT123508PEER-G ACP200  Nose Radius RE:.032" / 0.8,Wiper Facet Length wpr:.031" / .8 G:General-purpose, General-purpose:P,M Roughing:P,M

Coated Carbide:ACP300  ,Designation:AXMT123508PEER-G ACP300 Nose Radius RE:.032" / 0.8,Wiper Facet Length wpr:.031" / .8 G:General-purpose, General-purpose:P,M Roughing:P,M

Coated Carbide:ACP200 ,Designation:AXMT123508PEER-H ACP200 Nose Radius RE:.032" / 0.8,Wiper Facet Length wpr:.031" / .8 -H: Strong Edge, General-purpose:P,M Roughing:P,M

Coated Carbide:ACP300 ,Designation:AXMT123508PEER-H ACP300 Nose Radius RE:.032" / 0.8,Wiper Facet Length wpr:.031" / .8 -H: Strong Edge, General-purpose:P,M Roughing:P,M

Coated Carbide:ACK300 ,Designation:AXMT170504PEER-G ACK300 Nose Radius RE:.016,Wiper Facet Length wpr:.102 -G: General-purpose, Roughing:K

Coated Carbide:ACP200 ,Designation:AXMT170504PEER-G ACP200 Nose Radius RE:.016,Wiper Facet Length wpr:.102 -G: General-purpose, General-purpose:P,M Roughing:P,M
